Quick Guide

2

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories:

For information on comparative EN testing conditions, please send an email to the following address: dw_test_suppor[email protected]

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration by up to 20 min.

Program

Programs description

Drying

phase

NaturalDry

Available

options

*)

Duration

of wash

program

(h: min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- program is suitable to clean normally soiled ta-

bleware, that for this use, it is the most ecient program

in terms of its combined energy and water consump-

tion, and that it is used to assess compliance with the EU

Ecodesign legislation.

4:40 9.9 0.55

Auto Intensive 65° - Automatic

program for heavily soiled dishes

and pans.

Senses the level of

soiling on the dish-

es and adjusts the

program according-

ly. When the sensor

is detecting the soil

level an animation

appears in the dis-

play and the cycle

duration is updated.

2:25 - 3:10 17.0- 25.0 1.30 - 1.70

Auto Mixed 55° - Automatic pro-

gram for normally soiled dishes

with dried food residues.

1:20 - 3:20 7.5 - 20.5 0.75 - 1.20

Auto Fast 50° - Automatic program

for normally and lightly soiled dish-

es. The everyday cycle that ensures

optimal cleaning and drying perfor-

mance in shorter time.

1:00 - 1:50 8.0 - 16.0 0.70 - 1.10

Rapid 45° - Program is recommended for limited amount

of lightly-soiled dishes with no dried food residues. Does

not include the drying phase.

-

0:30 - 0:40 10.5 - 15.0 0.55 - 0.65

Crystals 45° - Program for delicate items, which are more

sensitive to high temperatures, for example glasses and cups.

1:40 - 1:50 12.5 - 17.0 0.95 - 1.20

Prewash - Use to refresh crockery planned to be washed

later. No detergent is to be used with this program.

-

0:12 4.5 0.10

Self-Clean 65° -

Program to be used to perform mainte-

nance of the dishwasher, to be carried out only when the

dishwasher is EMPTY using specic detergents designed

for dishwasher maintenance.

-

-

1:15 12.7 1.10

POWER CLEAN® - Thanks to the additional power jets this option

provides a more intensive and powerful wash in the lower rack, in the

specific area. This option is recommended for washing pots and casseroles

(Please refer to the Power Clean® loading section.

EXTRA DRY - The higher temperature during the final rinse and the

extended drying phase allow improved drying. The EXTRA DRY option

results in the lengthening of the wash cycle.

DELAY - The start of the program may be delayed for a period of time

between 0:30 and 24 hours.

The DELAY function cannot be set once a program has been started.

WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or

water tap is closed.

NaturalDry - It is aconvection drying system which automatically opens

the door during/after drying phase to ensure exceptional drying perfor-

mance every day. Door opens at the temperature that is safe to your kitch-

en furniture, thus door will not be opened when the option of SANI RINSE

is on. As additional steam protection, special designed protection foil is

added together with the dishwasher.

SILENT - Suitable for night-time operation of the appliance. This option

can be used to limit noise emission during wash phases. It will increase

cycle time depending on base cycle selection.

SANI RINSE - This option can be used to sanitize washed dishes. It will

increase the nal rinse temperature and add antibacterial wash to the

selected program. Ideal to clean crockery and feeding bottles. The dishwasher

door must be kept shut for the entire duration of the program in order to

guarantee reduction of germs. WARNING: the crockery and plates could

be extremely hot at the end of the cycle.

TURBO - Thanks to the Turbo option you can reduce time up to 40%

depending on the selected based program. Energy and water

consumption are increased.

HALF LOAD - If there are not many dishes to be washed, HALF LOAD is

used to save water, electricity or time, depending on the selected

program. Remember to halve the amount of detergent.

OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator

lights up) (see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rap-

idly 3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.

DESCALE – Alarm - Limescale accumulation was detected on the

internal components of the appliance. Check if the Water Hardness

Setting is at the correct value and salt is present in the salt container (see

FIRST TIME USE), then use a descaling product (WPro brand is recommended)

with Self-Clean program. After a successful descaling, the icon will stop

being displayed.

If the actions above are not performed, product performance will deteriorate.

DESCALE warning will start blinking and «dES» alarm will appear on the

display. If still no action is taken, the appliance will only allow a certain

number of cycles to be started (indicated during «dES» alarm display)

and then will be BLOCKED to prevent component damage, with only

the Self-Clean program available. Performing a full descaling will unblock

the product. In the case of extremely high amounts of limescale, descaling

may have to be performed twice to be ecient.

PROGRAMS TABLE

OPTIONS AND FUNCTIONS

Please scan the QR code on your product in order to have more detailed information.

TIME ON THE FLOOR - A LED light projected on the oor indicates the

time left to the end of the cycle. The light goes o every time the door

is opened. The light goes o at the end of a cycle.This feature is active

by default, but it is possible to deactivate it in the “SETTINGS MENU”.
