76

Lowest

cooling level

Highest

cooling level

Your refrigerator meets the climate class SN

requirements according to EN ISO 15502:2005 at

an ambient temperature 10°C to 32°C.

We advise to set the refrigerator on cooling

level 3, with an ambient temperature

between 15°C and 25°C. A higher temperature

needs a higher cooling level, a lower temperature a

lower level.

To improve the cooling performance of your

refrigerator in high temperatures, Thetford

advises to install the Ventilator Kit. It helps

to detract the warm air quicker to the vents.

The Ventilator Kit is suitable for all Thetford

refrigerators.

6 Control of optional extras

Batteries empty

present with the stand-alone models,

installed by your dealer.

When your refrigerator is provided with the

stand-alone option, it will run on 1.5V AA/LR6

batteries for approximately 7 days in combination

with gas supply.

When the red symbol ‘batteries empty’ blinks,

you must replace the batteries within 24 hours.

Remove all batteries out of the small cover

underneath the control panel and replace

6 new batteries. If you are not going to use this

function for more than two weeks, remove all

batteries.

Only use new 1.5V AA/LR6 batteries. Do not

use rechargeable batteries for this function

of the refrigerator.

If you don’t have enough batteries or want to

use your refrigerator for a very short period

it is also possible to only use 3 batteries in

a row. Your refrigerator will run for approximately

half a week now.

Anti-condensation

present on refrigerator model B

To prevent the control panel from condensation,

the anti-condensation function is automatically

switched on. Only switch off this function when

little energy is present.

Push both arrow buttons

together at once and hold

them for 2 seconds, as

illustrated. The symbol

‘anti-condensation off’ will

light up on the control panel. To switch on the

function again, push both arrow buttons for

2 seconds once more.

When your refrigerator runs on AA batteries, anti-

condensation is switched off automatically.

7 Use of refrigerator compartment

You can organise your refrigerator as desired by

moving the storage shelves and door bins

in height.

Make sure the door can still be closed after

reorganising shelves and bins.

Moving storage shelves

Turn the plastic clamp on

the right side of the storage

shelf upwards, as

illustrated. Lift the right

side a bit, and move the

storage shelf to the desired

position. First place the left

side of the storage shelf in

the refrigerator wall, then the right side in the

corresponding groove. Turn the plastic clamp

downwards. Your storage shelf is secured again.

Moving door bins

Push a door bin out of the

locking with both hands, as

illustrated. Place this door

bin back in the desired

position and push it back on

the locking. The door bin is

secured again.

Organising food

After a minimum of 8 hours of cooling, the food can

be placed in the refrigerator. Do not completely

cover the cooling fins with food, to preserve an

optimal performance of the refrigerator.

Make sure air can still circulate around the fins.

To prevent your refrigerator from ice-

formation, always cover liquid products,

let warm products cool down before placing them

in the refrigerator and don’t open the door any

longer than necessary.

3 Switch on refrigerator

To switch on the

refrigerator, push the on/off

switch and hold it for

1 second, as illustrated.

A light in the on/off switch

will turn green.

After 10 seconds the settings will dim.

The green light indicates the refrigerator is still in

function.

To check the settings push the on/off switch.

The last selected settings will light up.

To secure optimal performance, level your

vehicle before operating the refrigerator.

For optimal performance, switch on the

refrigerator 8 hours before placing food.

We advise to clean the inside of the

refrigerator properly, before using your

refrigerator.

4 Selecting source

After switching on the

refrigerator, push the

confirmation button and

hold it for 2 seconds. The

symbols for the sources

light up and start to blink.

Choose the desired source

by pushing the arrow

buttons.

Confirm your choice with

the confirmation button.

Sources

230V

The refrigerator is powered from

the mains.

12V

The refrigerator is powered from

the battery of your vehicle.

Gas

The refrigerator is powered from

the gas connection of a gas

bottle.

Always use the gas connection or mains voltage

to start up and cool. Operating on 12V is only

effective while the engine of the vehicle is running.

The performance of the refrigerator, when

operating on 12V, is dependent on the thickness

and length of the wiring and the overall installation

of the vehicle.

When selecting gas, the flame should be ignited

within 30 seconds. If the system fails, restart the

refrigerator and select the gas

source again.

From about 1000 m above sea level problems of a

physical nature can occur when lighting the gas.

This does not mean that the refrigerator is not

working properly.

Stand-alone model (if applicable)

The refrigerator is only functional, when the

control panel is powered.

A stand-alone model (installed by your dealer) is

operational using AA batteries in the event of no

mains or battery.

Therefore open the small

cover underneath the

control panel, as illustrated.

Insert 6 new 1.5V AA/LR6

batteries, according the

illustration in the cover.

5 Selecting cooling level

After switching on the

refrigerator, push the

confirmation button and

hold it for 2 seconds.

The symbols for the

sources start to blink.

Push the confirmation

button again.

The cooling level indicators

start to blink. Use the arrow

button to choose the

desired cooling level.

Confirm your choice with

the confirmation button.

GB GB
