Bedienungsanleitung Privileg P0F ECO D551 S Geschirrspüler

Bedienungsanleitung

ENQuick Guide

1

CONTROL PANEL

FIRST TIME USE

Before using the appliance carefully read Safety

Instructions guide.

PROGRAMS TABLE

PLEASE SCAN THE QR CODE ON YOUR

APPLIANCE IN ORDER TO HAVE MORE

DETAILED INFORMATION

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair).

Whenever you need to add salt, it is mandatory to complete the pro-

cedure before the beginning of the washing cycle to avoid corrosion.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid

dispenser A should be lled when the RINSE AID

REFILL indicator light in the control panel is lit.

NEVER pour the rinse aid directly into the

appliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce the

detergent into the dry dispenser D only. Place the amount of detergent for

pre-washing directly inside the tub.

If all-in-one detergents are used, we recommend using the TABLET button,

because it adjusts the program so that the best washing and drying results

are always achieved.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on heater, contributing also to better cleaning e-

ciency. This system regenerates itself with salt, therefore it is required

to rell salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

1. On-O / Reset button with indicator light

2. Program selection button with indicator light

3. Multizone button with indicator light / Tablet (Tab)

4. Eco program indicator light

5. Display

6. Program number and remaining time indicator

7. Tablet (Tab) indicator light

8. Closed water tap indicator light

Pro-

gram

Programs description

Drying

phase

Auto

Door

Available

options

*)

Duration

of wash

program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

1

Eco 50°- Program is suitable to clean normally soiled tableware, that for

this use, it is the most ecient programme in terms of its combined ener-

gy and water consumption, and that it is used to assess compliance with

the EU Ecodesign legislation.

4:00 9.5 0.64

2

Auto Intensive 65°- Automatic program for heavily soiled dishes and pans

(not to be used for delicate items).

2:00 - 3:10 14.0 - 17.0 1.50 - 1.85

3 Auto Mixed 55° - Automatic program for normally soiled pans and dishes.

1:30 - 2:30 14.5 - 16.0 1.15 - 1.30

4

Glass 45° - Program for delicate items, which are more sensitive to high

temperatures, for example glasses and cups.

1:40 12.0 1.20

5

Fast&Clean 28’ 45° - Program to be used for half load of lightly-soiled

dishes with no dried food residues. Does not include drying phase.

-

0:28 9.0 0.50

6

Silent 50° - Suitable for night-time operation of the appliance. Ensures op-

timal cleaning and drying performance with the lowest noise emission.

3:30 16.0 1.15

7

Prewash - Use to refresh crockery planned to be washed later. No deter-

gent to be used with this program.

-

-

0:12 4.5 0.01

8

Self Clean 65° - Program to be used to perform maintenance of the dish-

washer, to be carried out only when the dishwasher is EMPTY using spe-

cic detergents designed for dishwasher maintenance.

-

-

0:50 8.0 0.85

9

Push&GO 50° - Everyday wash and dry cycle that ensures great cleaning

performance in a short time without the need to pre-treat dishes.

1:25 11.5 1.10

9. Rinse Aid rell indicator

light

10. Salt rell indicator light

11. Push&Go button with

indicator light

12. Delay button with

indicator light

13. Start/Pause button with indicator light / Drain out

4

1

3

2

965 7 8 1210 11 13

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on com-

parative EN testing conditions, please send an email to the following address: [email protected]

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

A

C

D
