The mounting of the profile should be done during installation.

If not, please provide 1 cm between the top of the appliance

and the bottom of the work surface for air circulation, and

position the spacer delivered with the appliance.

2 GB

INSTALLATION

Installing a domestic appliance can be a complicated operation which if not carried out correctly, can seriously affect

consumer safety.

It is for this reason that a professionally qualified person should undertake the task who will carry it out in accordance

with the technical regulations in force.

In the event that this advice is ignored and the installation is carried out by an unqualified person, the manufacturer declines

all responsibility for any technical failure of the product whether or not it results in damage to goods or injury to individuals.

ELECTRICAL CONNECTION

"The installation must conform to the standard directives".

The manufacturer declines all responsibility for any damage that

may be caused by unsuitable or unreasonable use.

Warning :

• Always check before any electrical operation, the supply tension

shown on the electricity meter, the adjustment of the circuit-

breaker, the continuity of the connection to earth to the installation

and that the fuse is suitable.

• The electrical connection to the installation should be made via

a socket with a plug with earth, or via an omni pole cut-out

switch.

If the appliance has a socket outlet, it must be installed so that

the socket outlet is accessible.

The manufacturer cannot be held responsible for any accidents

resulting from the use of an appliance which is not connected

to earth, or with a faulty earth connection continuity.

• Any queries regarding the power supply cord should be referred

to After Sales Service or a qualified technician.

Warning! This appliance must be earthed. In the absence of

adequate earthing you will notice that when touching the

metal parts of your appliance an electrical dispersion can be

felt due to the presence of a radio interference suppressor.

• DUO

A power cord is supplied with the DUO which allows it to be

connected only to a power supply of 220-240 V between

phases, or between phase and neutral.

• Connect to a 10/16 Amp socket.

WATER CONNECTION :

The inlet and drain hoses can be directed to left or right.

The dishwasher can be connected to either cold or hot water, as

long as it is no hotter than 60°C.

Water pressure must be between 0,08 MPa and 0,8 MPa. If the

pressure is below the minimum consult the service department

for advice.

The inlet hose must be connected to a tap so that the water supply

can be cut off when the machine is not in use (fig.1). The dishwasher

inlet hose is fitted with a 3/4" threaded connector (fig.2). The inlet

hose "A" should be tightly connected to a 3/4" tap "B".

The water connection of the dishwasher must be done exclusively

with the pipe supplied.

Do not use an old pipe.

If the machine is connected to new pipes or to pipes which have

not been in use for long time, run water through for a few minutes

before connecting the inlet hose. In this way no deposits of sand

or rust will clog up the water inflow filter.

The hose can be hooked over the side of the sink (it must not be

immersed in water, in order to prevent water from being siphoned

back to the machine when this is in operation) Check that there

are no kinks in the inlet and outlet hoses. To extend, if necessary

the intlet hose, contact the Customer Service.

WATER CONNECTION - WATER DRAINAGE

4

WATER DRAINAGE :

Take care not to bend or kink the drain hose when connecting it

to the machine so that the water can drain freely from it (fig.3y).

The drain hose must be at least 40 cm above floor level and it

must have an internal diameter of at least 4 cm. It is advisable to

fit an anti-odour air trap (fig.3x).

If necessary, the outlet hose can be extended up to 2,6 m, provided

that it is kept at a maximum height of 85 cm above floor level. For

this, contact Customer Service.

WARNING!

3

D
