Bedienungsanleitung Timex TW2V37300JR Waterbury Armbanduhr

Bedienungsanleitung

3

ENGLISH 990-095926-07

PERPETUAL CALENDAR

Your Perpetual Calendar watch accurately keeps track of how many days are in

each month. It also adjusts for leap years. The date on your watch (including the

month and year) was preset at the factory to Eastern Standard Time, Greenwich

Mean Time or Hong Kong Standard Time (depending on where you purchased

your watch). You only need to adjust the time.

I

I

WED 14

I

I

WED 14

CHECK DATE

(FACTORY USE ONLY)

SET TIME

DAY, DATE

MIDDLE OUT

TO SET TIME

To set time, simply pull crown all the way out and turn. Day and date change

automatically when time is adjusted past midnight; there is no additional step for

setting day or date. Push crown in when done.

After setting, if date changes at noon, time needs to be adjusted ahead or back

12 hours.

If crown is accidentally put in MIDDLE position and turned, date display will

change temporarily, but date setting is unaected. Simply pull crown all the way

out and set time. Proper date display will resume.

PERPETUAL CALENDAR WATCH

FREE LIFETIME BATTERY REPLACEMENT**

If the battery needs to be changed, we recommend that only TIMEX replace it.

Your watch will need to be recalibrated to correct time and date after changing the

battery. To return your watch to Timex, visit the retailer where you purchased your

watch or go to http://www.timex.com/productWarranty.html for information on

contacting Timex.

** Shipping & handling charges apply.

NEVER INCLUDE A SPECIAL WATCHBAND OR ANY OTHER ARTICLE

OF PERSONAL VALUE IN YOUR SHIPMENT.

ELAPSED TIME RING

If your watch is equipped with a rotatable outer ring on the face, with numbers

corresponding to minutes, you can use this Elapsed Time Ring to time an

activity from the start, or to mark the ending time for the duration of an activity.

TO TIME AN ACTIVITY FROM THE START:

Set the Start/Stop triangle at the time (hour or minute) when you start the

activity (As shown on the left in the illustration shown below). At completion, you

can see how long the activity took.

TO MEASURE THE TIME REMAINING:

Set the triangle to the hour or minute position when you wish to complete the

activity, and check the watch periodically for progress towards that goal.

In the illustration shown on the previous page on the right you can stop when

the minute hand reaches the 20 minutes past the hour position.

TACHYMETER RING

The tachymeter feature can be used to measure speed in miles per hour (MPH),

nautical miles per hour (knots) or kilometers per hour (KPH) using the sweep

second hand and the scale on the wall above the watch face. You need to know

the actual distance you are covering in miles or km.

Start the chronograph with the second hand at zero (the twelve o’clock position).

Within the first minute, the second hand will point to the rate for a one-mile (or

one kilometer) course: if it takes 45 seconds, the hand will point to 80 at that

position – 80 MPH or 80 KPH.

If within the first minute, a distance greater than one mile or kilometer is covered,

multiply the tachymeter number by the distance to get the actual rate: if you went

1.2 miles in 45 seconds, multiply the 80 by 1.2 – 96 MPH.

COMPASS RING

If your watch is equipped with a movable ring around the dial marked at the

letters “N”, “E”, “W”, “S” (for the four compass directions) or compass degrees,

you can use this feature to find an approximate compass directional reading.

1. Lay the watch on a flat surface, or hold it so that the face is parallel to the

ground.

2. Locate the sun and point the hour hand at the sun.

3. In the A.M., rotate the ring until the “S” (south) marker is halfway between

the hour hand and 12:00 (after the hour hand or within the shortest distance

between the hour hand and 12:00).

4. In the P.M., rotate the ring until “S” is before the hour hand and halfway

between the hour hand and 12:00.

12

1

2

3

4

5

6

7

8

9

10

11

N

S

W

E

HOW TO ADJUST BRACELET

(Variations of the following bracelet sections apply to all watch models).

SLIDING CLASP BRACELET

1. Open locking plate.

2. Move clasp to desired bracelet length.

3. Exert pressure while holding locking plate and slide clasp back and forth until

it engages in grooves on underside of bracelet.

4. Press locking plate down until it snaps closed. Clasp can be damaged if

excessive force is used.

FOLDOVER CLASP BRACELET

1. Find spring bar that connects bracelet to clasp.

2. Using a pointed tool, push in spring bar and gently twist bracelet to

disengage.

3. Determine wrist size, then insert spring bar in correct bottom hole.

4. Push down on spring bar, align with top hole and release to lock in place.

FIG. 1 FIG. 2 FIG. 3
