Battery Installation - See Battery Installation Diagram

Princeton Tec cares about the environment and

recommends recycling batteries. For more information

about battery recycling, please go to:

www.batteryrecycling.com

Observe proper battery polarity when installing the

batteries. Improper installation of the batteries will

damage the light and void the warranty.

WARNING

• Never mix fresh and used batteries.

• Never mix different battery brands or chemistry types.

• Always remove drained batteries immediately.

• Remove batteries during long periods of storage.

Switch Operation – See Switch Operation Diagram

• Modes (High, Low, and Flash) are selected by

pressing and releasing the large push button on the

rear of the light.

• To turn the PUSH off, cycle through the modes (a

total of 3 button pushes) until the ‘off’ mode is enabled.

• To turn off the red side flashers, while the light is on,

hold down the rear button for FIVE SECONDS in any

mode. Once this is done, the standard front LED will

operate normally without the side flashers. Once the

red side flashers go off, they will not turn back on until

the rear button is held down for FIVE SECONDS again.

Installation – See Installation Diagram

To install the Push onto handlebars, align the upper

grey rubber piece towards the front of the bars. Make

sure that the light will be directed at an appropriate

angle when tightened in that position. Next, unscrew

the bracket screw to an appropriate length, close the

bottom part of the bracket so that it is at your desired

location for the light. The bracket screw goes into the

notch on the bottom half of the bracket, screw down

until an appropriate tightness is achieved.

To remove the Push from the handlebar bracket press

downward on the tab beneath the switch and slide the

Push back towards the tab.

The Push can rotate 15º left and right for optimal

beam placement. Once the light is installed on the

handlebars, hold the top of the light and pivot in the

desired direction.

Troubleshooting

If the PUSH fails to light:

• Check the batteries for proper installation.

• Replace batteries if proper installation is confirmed.

• Check module for water. The PUSH was designed to

INCLUDED IN THIS WARRANTY. (Some states do not

allow the exclusion or limitation of incidental or

consequential damages, so the above limitations or

exclusions may not apply to you.) This warranty gives

you specific legal rights, and you may also have other

rights which vary from state to state.

Princeton Tec reserves the right to change product

specifications without notice.

Return Policy

If your light fails to operate, follow these simple steps:

1) Check batteries. Replace if necessary.

2) Contact Princeton Tec customer service at

800-257-9080 to request an RMA number to send your

light in for repair or replacement. No warranty repairs

will be accepted without an RMA number.

3) Return the light without batteries to: Princeton Tec,

5198 Rt. 130, Bordentown, NJ 08505. Postage due

and freight collect items will not be accepted.

Princeton Tec

PO Box 8057,

Trenton, NJ 08650

Phone: 609-298-9331

Fax: 609-298-9601

www.princetontec.com

© 2013 Princeton Tec

be water resistant. However, it is not waterproof, so

there is a possibility that water or moisture could be

inside the module. The light will resume normal

operation once the water is shaken or blown out and

the light is left open until completely dry. If the light has

been contaminated with salt water, flush the unit with

fresh water and dry as described above.

Riding at Night

CAUTION: Please remember that cycling at night is an

inherently dangerous activity. The Push will improve

your visibility and nighttime cycling enjoyment.

PLEASE RIDE WITH CAUTION AND REMEMBER TO:

• Wear reflective clothing

• Always wear a helmet

• Attach a Princeton Tec® SWERVE tail flasher to your

bike for added visibility.

USA– International 3-Year Warranty

WARRANTY – Princeton Tec warrants this product to be

free from defects in workmanship and materials under

normal use for as long as you own this product. This

warranty covers all of the component parts of the

product except batteries. This warranty does not cover

deterioration due to normal wear or damage due to

misuse, alteration, negligence, accidents, or

unauthorized repair. Princeton Tec will repair or replace

parts which are defective in workmanship or materials.

Your authorized Princeton Tec Dealer and Princeton Tec

are the only facilities authorized to repair the product.

After (3) unsuccessful attempts (within the warranty

period) to repair the product, you have the right to elect

replacement of the product or a refund of the purchase

price less allowance for use of the product. NO

INCIDENTAL OR CONSEQUENTIAL DAMAGES ARE

PUSH

TM

LED BIKE LIGHT

press 1x = High

press 2x = Low

press 3x = Flash

1 MAXBRIGHT

LED

DISTANCE (Meters)

10 38 66

HIGH

4H

FLASH

63 H

LOW

14H

3

1 2

1

OPEN

CLOSE

2

3 4

15º
