IFM0S62

ENGLISH

I

INSTRUCTION MANUAL

A) DISPLAYS AND BUTTONS

B) SETTING THE TIME

1. Pull the crown out to the 2nd Click Position so that the second hand stops at ZERO position.

2. Turn the crown to set hour and minute hands.

3. When the crown is pushed back to the normal position in synchronization with a time signal, small second hand begins to run.

C) SETTING THE DATE

1. Pull the crown out to the 1st Click Position.

2. Turn the crown anticlockwise to set the date.

* If the date is set between the hours of around 9:00 PM and 1:00 AM, the date may not change on the following day.

3. After the date has been set, push the crown back to the normal position.

D) USING THE CHRONOGRAPH

This chronograph is able to measure and display time in 1/20(1/1) second united up to max 11hrs 59 min 59 sec.

The retrograde chronograph 1/20(1/1) second hand keeps continuously for 60 seconds after starting,and then stops at ZERO position.

Measuring time with the chronograph

1. Press button “B” to change the watch to the chronograph mode.

The second hand stops at the ZERO second position, and changes to the chronograph 1/20(1/1) second hand.

2. The chronograph can be started and stopped each time button “A” is pressed.

The chronograph 1/20(1/1) second hand stops at the ZERO second position 60 seconds after starting, When button “A” is pressed to stop

the chronograph, the chronograph 1/20(1/1) second hand advances rapidly to display the measured time.

3. Pressing button “B” resets the chronograph and all hands return to their ZERO positions.

* Moving of the retrograde chronograph is a demo.

Actual measurement will be shown when it stopped / STOP button is pushed.

E) CHRONOGRAPH RESET (INCL. AFTER REPLACING BATTERY)

This procedure should be performed when the chronograph second hand and chronograph 1/20(1/1) second hand do not return to the ZERO

second position after the chronograph has been reset, and including after the battery has been replaced.

1. Pull the crown out to the 2nd Click Position.

2. Press button “A” to set the chronograph second hand to the ZERO position.

3. Press button “B” to set the chronograph 1/20 second hand to ZERO position.

The chronograph hands can be advanced rapidly by continuously pressing button “A” or “B”.

4. Once the hands have been zeroed, reset the time and return the crown to its normal position

5. Press button “B” to check that the chronograph hands are reset to the ZERO position

* Do not return crown to the normal position while chronograph second hand and 1/20 chronograph second hand return to ZERO position.

Each hands stop on the way when crown are returned to normal position and these positions are recognized as ZERO position

"A"

RESET

"A"

TIME MEASUREMENT STOP

"B "

"A"

"B"

Hour hand

Second hand or 1/20 sec chronograph hand

Button B

Button A

Minute hand

1st Click Position

2nd Click Position

Normal crown position

Calendar

Chronograph

second hand

Chronograph

hour hand

Chronograph minute hand

By virtue of the regulations pursuant to the handling of waste products deriving from electronic and electrical equipment, end of lifecycle watch making

products must be selectively collected for processing. You may therefore dispose of your quartz watch making products at any of our retail outlets or any other

authorized collection point. The selective collection, processing, rating and recycling of these products helps contribute to safeguarding the environment and

protecting our health.
