Bedienungsanleitung Clas Ohlson MP2406 Mp3 player

Bedienungsanleitung

English

GREAT BRITAIN • customer service

tel: 0845 300 9799 e-mail: [email protected] internet: www.clasohlson.com/uk

MIC

1

4

5

6

2

3

MIC

1

4

5

6

2

3

MIC

11

12

13

17

14

18

15

19

16

20

21

22

MIC

7 8 9 10

YES

NO

Ver. 20140326

4 GB MP3 Player with Radio

Art.no 38-6207 Model MP2406

Please read theentire instruction manual before using theproduct and then save

it for future reference. We reserve theright for any errors in text or images and any

necessary changes made to technical data. In theevent of technical problems or

other queries, please contact our Customer Services.

Safety

• Never expose theMP3 player to constant sunlight, heat sources,

moisture or rain.

• Do not expose theMP3 player to hard knocks or blows.

• Do not place theMP3 player close to strong magnetic fields

(speaker drivers, etc.).

• Do not place theMP3 player in your pocket together with other

objects such as keys.

Note: Protect your hearing. Listening to thespeaker on high volume for

prolonged periods can lead to permanent hearing damage.

Turning thedevice on/off and charging

1. Use thesupplied charger cable to fully charge theMP3 player before use.

Thecharge indicator will appear in thedisplay during charging. Thedisplay

will show “Low battery” whenever thedevice needs to be charged.

2. Turn on thedevice by pressing [ ] for 3 sec.

3. Turn off thedevice by pressing [ ] for 3 sec.

4. Theplayer will turn off automatically after 2 min of non-use (unless connected

to acomputer).

Language

1. Hold in [ M ] until themain menu appears.

2. Select settings (at thebottom left of thedisplay).

3. Press [ M ] to access thesub-menu.

4. Select Language and then thedesired language.

5. Press [ M ] to confirm.

Transferring files

1. Connect theplayer to acomputer using thesupplied USB lead.

Two selections will be given. “Charge and transfer” and ”Charge and play”.

2. Select Charge and transfer. Transfer thefiles according to thespecific

instructions for thesoftware you are using to complete such atask.

Key lock

Short press [ ] to activate thekey lock. Press again to unlock.

Playback

Main menu

Hold in [ M ] for main menu access.

1. [ ▲ ] Volume up

2. [ ◄ ] Short press: Previous track.

Hold in to rewind.

3. [ ▼ ] Volume down

4. [ ►ll ] Play/pause

5. [ M ] Short press: Advances through

menu selections. Hold in:

Accesses main menu.

6. [ ◄ ] Short press: Next track.

Hold in: Fast forward.

Buttons and functions

Menu functions

1. [ ▲ ] Up

2. [ ◄ ] Exit

3. [ ▼ ] Down

4. [ ►ll ] Select/confirm

5. [ M ] Short press: Advances through

menu selections. Hold in: Accesses

main menu.

6. [ ► ] Right, accesses sub-menu

7. Micro USB port for charging/

data transfer.

8. Microphone

9. [

] Hold in (3 sec): On/off.

Short press: Lock/unlock

10. 3.5 mm headphone jack

11. Micro-SD slot

12. [ Reset ] Original factory default settings

13. Music

14. Video

15. Tools

16. Settings

17. Record

18. Folders

19. Radio

20. Image

21. E-books

22. Displays thecurrently recorded (music) file

Sub-menus

• Sub-menus are shown after pressing [ ► ] [ ▼ ] [ ◄ ] [ ▲ ] from themain menu

and then pressing [ M ].

• Navigate themenus in thesame way as described in theButtons and functions -

Menu functions section above.

Music

• All songs

• Artists

• Albums

• Genres

• Album art

• Audiobooks

• Playlists

• MediaLib Update: Media library update

• Local folder: MP3 player memory

• Card folder: Memory card memory

Pressing [ M ] during playback or stop mode will cause

thefollowing sub-menus to appear:

• Play mode: Playback settings

• Sound settings

• Add to playlist

• Remove from playlist

• Sleep timer

• Delete

• Bookmarks

Video

• Local folder: MP3 player memory

• Card folder: Memory card memory

Pressing [ M ] during playback or stop mode will cause

thefollowing sub-menus to appear:

• Brightness

• Repeat

• Delete video

• MediaLib Update: Media library update

Volume

TheMP3 player has abuilt in volume limiter

which is factory set to prevent hearing

damage during extended listening. Increasing

thevolume above volume level 23 will prompt

awarning in thedisplay:

Select YES with [ ◄ ] to allow for higher volume.
