English

GREAT BRITAIN • customer service

tel: 020 8247 9300 e-mail [email protected] internet www.clasohlson.co.uk postal 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ

1

2

3 4

5

6

7

Ver. 20171207

Indoor/Outdoor

Thermometer

Art.no 36-6722 Model E0108T2C

36-6722-1 E0108T2C

Please read theentire instruction manual before using theproduct

and then save it for future reference. We reserve theright for any

errors in text or images and any necessary changes made to

technical data. In theevent of technical problems or other queries,

please contact our Customer Services.

Safety

• Thethermometer must not be dismantled or modified in

any way.

• Thethermometer is only intended for indoor use.

Do not expose it to moisture.

• Thethermometer is not intended to be used as areference

thermometer and Clas Ohlson will not be held liable for any

damage which may result from inaccurate readings.

• Thebatteries should be removed from thethermometer if it is

not to be used for anextended period, otherwise they might

leak and damage thethermometer. Never leave adischarged

battery in thebattery compartment.

• Themax and min readings will be deleted whenever

thebatteries are is removed.

• Thethermometer must never be subjected to shocks

or impacts.

Note:

• Do not mix old and new batteries or batteries of different types.

• Do not mix alkaline, regular or rechargeable batteries.

Buttons and functions Operating instructions

1. Select theunits, Celsius or Fahrenheit, using the [ C/F ]

button (3).

2. Press [ MAX/MIN ] (4) to display themaximum or minimum

temperature. Thedisplay will return to displaying thecurrent

temperature after afew seconds.

3. Hold [ MAX/MIN ] pressed down for afew seconds to clear

themax/min temperature memory.

Care and maintenance

Clean theproduct using alightly moistened cloth. Use only mild

cleaning agents, never solvents or corrosive chemicals.

Troubleshooting

If “HH” or “LL” appears, it means that themeasured

temperature lies outside of thethermometer’s range.

Responsible disposal

1. Outdoor temperature

2. Indoor temperature

3. [ C/F ] For selecting temperature unit, ºC or ºF

4. [ MAX/MIN ] Select min/max temperature display mode

5. Hanging slot

6. Table stand

7. Battery cover

Installation

1. Slide thebattery cover (7) down to access thebattery

compartment.

2. Insert 2×AAA/LR03 batteries (sold separately) observing

thepolarity markings in thebattery compartment.

3. Click thebattery cover back into place.

4. Choose where thethermometer is to be placed:

- Standing on aflat surface using thetable stand (6).

- Hanging on awall using thehanging slot (5).

5. Make sure that theend of thesensor lead is outside so that

theit can register theoutdoor temperature.

This symbol indicates that this product should

not be disposed of with general household

waste. This applies throughout theentire EU. In

order to prevent any harm to theenvironment

or health hazards caused by incorrect waste

disposal, theproduct must be handed in for

recycling so that thematerial can be disposed

of in aresponsible manner. When recycling your product,

take it to your local collection facility or contact theplace of

purchase. They will ensure that theproduct is disposed of in

anenvironmentally sound manner.

Specifications

Temperature (indoor) 0 to 50 ºC (32 to 122 ºF)

Temperature (outdoor) −30 to 60 ºC (−22 to 140 ºF)

Accuracy ±0.5 ºC

Batteries 2×AAA/LR03 (sold separately)

Size 62×97×15 mm

Sensor lead 1.5 m

Weight 66 g
