ENGLISH

7

5. CONNECTING SUBWOOFER PREOUT

• To emphasize the deep bass sounds, connect a powered

subwoofer.

SUBWOOFER

OUT

4. CONNECTING DIGITAL INS

• The OPTICAL and the COAXIAL DIGITAL OUTs of the

components that are connected to CD, VIDEO 1 and VIDEO 2 of

this unit can be connected to these DIGITAL INs.

• A digital input should be connected to the components such as a

CD player, DVD player, etc. capable of outputting DTS Digital

Surround, Dolby Digital or PCM format digital signals, etc.

• For details, refer to the operating instructions of the component

connected.

• When making the COAXIAL DIGITAL connection, be sure to use

a 75Ω COAXIAL cord, not a conventional AUDIO cord.

• Some of the commercially available optical fiber cords cannot be

used for the equipment. If there is an optical fiber cord which

cannot be connected to your equipment, consult your dealer or

nearest service organization.

■Note :

• Be sure to make either a OPTICAL or a COAXIAL DIGITAL

connection on each component. (You don’t need to do both.)

■Digital input default settings

• If you connect the DIGITAL INs to your components, it is easier to do so following the default settings.

• If your DIGITAL connections are different from default settings, you should assign the DIGITAL INs you used with the “When

selecting the DIGITAL IN” procedure on page 41.

• The default settings are as follows :

OPTICAL IN : VIDEO 1, COAX 1 IN : VIDEO 2, COAX 2 IN : CD

D

IGITAL IN

COAX 2

(CD)

OPT

(V

IDEO 1

)

C

OAX 1

(V

IDEO 2

)

• To connect this unit to a broadband home network to listen to internet radio broadcast, connect the LAN/ETHERNET

connector of this unit to your router with a Ethernet cable (CAT-5 or greater recommended).

■Notes :

• After making a broadband internet connection, you should set the communication settings.

(For details, see “When selecting “Network”” on page 32.)

• When using a broadband internet connection, a contract with an internet service provider is required.

For more information, contact your nearest internet service provider.

• Refer to the operating instructions of the equipment because the connected equipment and connection method may differ

depending on your internet environment.

• Use a Ethernet cable/router supporting 10 BASE-T/100 BASE-TX.

• Some Ethernet cables are easily affected by noise. We recommend using a sheilded type cable.

6. CONNECTING TO NETWORK

LAN / ETHERNET

LAN

Internet Modem PCBroadband router

RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 7
