4. Electrical Connection

The voltage specified on the type plate must match the local

mains voltage.

If the power cord of this device is damaged, it must be replaced

by the manufacturer or after-sales service, or else by a similarly

qualified person, in order to prevent risks.

The device plug must always be accessible.

In order to avoid a hazard due to inadvertent resetting of the

thermal cut-out, this appliance must not be supplied through an

external switching device, such as a timer, or connected to a

circuit that is regularly switched on and off by the utility.

5. Operation

The room temperature is regulated using the infinitely

adjustable thermostat (C). If the rotary knob is set to the lowest

setting i.e. to the extreme left (see figure), the thermostat

switches the heating device on at an ambient temperature of

approx. 5°C.

The heating device is switched on and off using the power

switch (D).

Two heating levels (I = 1000W or II = 2000W) can be selected

using the operating mode switch (E).

The red light illuminates when the device is in heating

operation.

Note!

Rooms can become overheated if left unattended whilst being

heated; this depends on the size of the room, its heating

requirements and the setting of the thermostat. Persons who

are not able to vacate the room if the temperature becomes too

high can thus be placed in danger.

5.1 Fan operation (device type K 821 only)

Switch F switches on a fan which causes faster heat

distribution through increased air recirculation.

The fan can also be used as cold air fan.

In cold air fan operation, turn the thermostat rotary knob to the

maximum (clockwise).

6. Protection Against Overheating

If the permissible temperature is exceeded, the heating device

switches off automatically. If this occurs, pull the mains plug out

and leave the device unplugged for a few minutes, so that the

temperature limiter can switch back again.

Then remove the cause e.g. when the air grid is blocked or

covered. When the device has cooled sufficiently, it can be

started up again.

7. Faults

If the heating device does not give off heat, check the following

points:

• Is the power switch (B) in the ON position?

• Has the thermostat been set to the desired temperature?

• Has the overheat protection been triggered? See chapter 6!

• Is the fuse in the fuse box switched on?

If you cannot remedy the fault, please contact your electrical

retailer. If required, you can also address your queries to the

service hotline of Glen Dimplex Deutschland GmbH.

Tel.: +49 (0) 9221 709-564

Fax: +49 (0) 9221 709-589

To process your order, please state the device type as well as

its production number (E Nr.) and manufacturing date (FD).

This information is listed on the type plate.

Repairs and corrective measures may only be carried out by a

qualified electrician or by your after-sales service.

8. Cleaning

To clean the device, first disconnect it from the mains and allow

it to cool down. Clean the outside of the unit using a soft, damp

cloth. Do not use scouring powder or furniture polish as this

may damage the surface. Dust which gathers inside the device

can be removed from the outside using a vacuum cleaner.

9. Warranty

This product is supplied with a two-year warranty according to

our terms of guarantee.

10. Note on Disposal

Do not dispose of the unit with general household

waste. The device must be taken to a local waste

disposal plant.

EN
