Installation and Operating Instructions

Convector K 811, K 821

1. Important Information

Keep these instructions in a safe place and pass them on to

possible future owners.

• Use device for room heating within enclosed rooms only.

• Repairs and corrective measures may only be carried out by

a qualified technician.

• Disconnect the power supply in the event of fault (pull out

the device plug or switch off the fuse).

• Do not use this device next to the bathtub, shower,

washbasin or swimming pool.

• Do not cover the heating device with any objects;

fire hazard! The device carries the symbol shown

on the right, which indicates that the heating

device must under no circumstances be covered

with any objects.

• Observe the minimum clearances.

• Caution! The outer surfaces of the device, and in particular

the air outlet grid, become hot during operation.

• Children or persons who are not capable of operating the

device safely must not operate the heating device. Ensure

that children do not play with the device.

• Caution! Potential dangers can arise when the device

switches on automatically, e.g. devices which have been

covered or blocked by objects since they were last used can

cause fire.

• Do not operate the heating device in rooms where highly

flammable substances are used (e.g. solvents, etc.).

• Do not lay the connecting cable across the hot device.

• In order to avoid a hazard due to inadvertent resetting of the

thermal cut-out, this appliance must not be supplied through

an external switching device, such as a timer, or connected

to a circuit that is regularly switched on and off by the utility.

2. Technical data

Heat output: 2000 W

Connection voltage: 1/N/PE~, 230 - 240 V, 50 Hz

Protection type: IP20

Protection class: I (with protective conductor)

Dimensions:

free-standing (W x H x D) 575 x 418 x 200 mm

wall-mounted (W x H x D) 575 x 345 x 120 mm

Weight: 3.5 kg (K 811), 4.1 kg (K 821)

3. Installation

The heating device may only be installed as shown, i.e. on a

horizontal, even surface. Using it on deep-pile carpets is not

permitted. Please use caution when installing it in front of

flammable objects. Installation below a wall socket is not

permissible. Minimum clearances must be observed.

In addition, a minimum clearance of 500 mm between

flammable objects e.g. curtains, towels or heat-sensitive

plastics and the front of the unit must be maintained.

Installation of the supporting feet

Do not use the heating device without the feet being fitted.

The two mounting screws for

the supporting feet (A) are

located on the bottom of the

device. Loosen the mounting

screws.

Engage the supporting feet as

shown in the illustration and

tighten the screws.

Wall mounting

The device plug must be accessible after installation.

The heating device must be aligned horizontally and installed

on a vertical wall (see illustration).

Make sure that the inflow and outflow of air at the top and

bottom of the device are unimpeded

.

Install the device in such a manner that the controls cannot be

touched by a person in the bathtub or under the shower.

It is not permissible to install the device in protection zones as

defined in VDE 0100 part 701.

The wall brackets (B) attached to the bottom of the device must

be used.

- Drill mounting holes for the two upper wall brackets 358 mm

apart and insert dowels.

- Attach the upper wall brackets by tightening the screws and

hook the heating device on.

- Insert the third wall bracket into the lower back panel slot.

- Check the horizontal alignment of the heating device and

mark the hole for the lower wall bracket.

- Remove the heating device, drill mounting hole for the lower

wall bracket and insert dowel.

- Hook the heating device back onto the upper wall brackets

and screw the lower wall bracket to the wall.

EN
