• HIGH DEFINITION SOUND
Place the Parent Unit into its docking station for High Denition Sound monitoring.
• PAGING
Locate a lost Parent Unit by pressing the
button on the Baby Unit 3 times in quick succession and the Parent Unit
will sound a 1-minute long alarm. To silence the alarm, press any button on the Parent Unit. Please note that the
paging feature will only work when both units are switched ON and monitoring as normal.
• BELT CLIP
Locate the rubber cover on the back of the Parent Unit and the belt
clip attachment supplied. Remove and carefully store the rubber cover,
then line up the belt clip’s guiding pins (image 1), insert the clip in
Position
and turn 90 degrees in a clockwise direction to position
. Alternatively, the belt clip can be orientated so that you can wall
mount or hang your Parent Unit. In which case, line up the belt clip’s
guiding pins (image 2), insert the clip in position and turn 90
degrees in a clockwise direction to position .
• INDEPENDENT NIGHTLIGHT
TIMER
AND TEMPERATURE DISPLAY
As your baby grows older you can use the Nightlight, Temperature display and Timer without monitoring and without the
need for the Parent Unit.
With the Baby Unit switched OFF, press and hold the button and the Nightlight will illuminate. The button
will glow red (instead of the usual green), indicating that the monitor is not switched ON. Repeat the operations
described earlier for colour scroll, colour selection and extending battery life.
• ACCESSORIES; TOMY’S MOVEMENT SENSOR PAD MONITOR AND ADDITIONAL PARENT UNITS
For extra reassurance Tomy’s Movement Sensor Pad Monitor and/or an additional Parent Unit from either the Tomy
Digital or Digital Plus models can be added to your Monitor. For further details please visit our website: www.tomy.eu
• CARING FOR YOUR MONITOR
Do not immerse any parts in liquids. Do not place in direct sunlight. Periodically examine product for signs of
damage to electrical parts and do not use until damage has been properly repaired. Always remove batteries from
the Baby Unit if using the mains adaptor for long periods of time.
• GUARANTEE
We guarantee your monitor against manufacturing defects for 2 years from the date of purchase on production of
a valid receipt. In the rst instance of a manufacturing defect, we recommend that you return your monitor to its
place of purchase. If this does not satisfactorily resolve your problem, please refer to www.tomy.eu for further advice.
Full terms and conditions can be found on our website: www.tomy.eu
• TECHNICAL SPECIFICATIONS
- Power Supply: Mains adaptor rating: PRI: 230V~50Hz SEC: 6V
300mA.
- Batteries: Parent Unit - Rechargeable 850mAh 2.4V Ni-MH battery (included).
Baby Unit - Requires 4 x 1.5V AA (LR6) batteries.
- Operating Range: 350m in optimum ‘open eld’ conditions.
- Operating Temperature: 0 - 50ºc.
- Frequencies: 1880~1900MHz.
• VOLUME CONTROL
Adjust the volume from zero (mute) to level 8 (max) by moving the thumb wheel clockwise to increase or anti-
clockwise to decrease.
• SOUND LEVEL LIGHTS DISPLAY
The Sound Level Lights Display on your Parent Unit reacts to the sounds of your baby. The louder your baby, the more
lights illuminate on the display. You can lower the volume of the Parent Unit whilst still watching out for baby, Ideal
for when you’re relaxing or entertaining.
• SOUND ACTIVATED MONITORING
For those quiet moments or when your baby is a little older you may not want to hear every sound in your baby’s
room. Your Baby Monitor has a Sound Activated Monitoring mode, a feature that only captures sounds above a pre-
set threshold, for example a cry rather than a gurgle.
Select Sound Activated Monitoring by pressing the
button on the Parent Unit. The Parent Unit will mute
15 seconds after your baby settles. Every time your baby’s sounds rise above the threshold this feature will be
interrupted instantly and normal sound monitoring will continue until your baby settles again.
• 2-WAY TALKBACK
For that little extra reassurance and convenience, your monitor has a 2-Way Talkback feature that allows you
to speak to your baby. Press and hold down the
button on the side of the Parent Unit to activate and speak to
your baby.
• VIBRATE ALERT
Perfect for monitoring with or without the sound. Every time your baby’s sounds rise above the threshold, the
monitor will vibrate until your baby settles again.
Activate by pressing the
button on your Parent Unit. Your Parent Unit will vibrate with every alarm and sound
from your baby above the pre-set threshold.
This feature is great for the hard of hearing.
• TIMER
Tomy have added a Timer so you can keep track of the interval between feeds/doses of
medication or how long your child has been asleep and so on.
Activate the Timer by pressing the
button, either on the Baby Unit or on the Parent Unit.
To restart press the button once. To deactivate, press and hold until the timer disappears from the display.
Please note that the Timer will automatically switch off when both units are powered down.
• MULTICOLOUR NIGHTLIGHT
Your monitor has a unique Multicolour Nightlight feature. Set it to scroll through the colours of the rainbow or
simply light up in one colour.
Activate the Nightlight by pressing the
button on your Baby Unit or remotely from your Parent Unit.
With the Nightlight ON, press and hold the
button on the Baby Unit for 2 seconds until the Nightlight starts to change
colour, scrolling through the colours of the rainbow. Multicoloured Nightlight can only be activated from the Baby Unit.
As the colour changes, a single press of the
button on the Baby Unit only will end the rainbow sequence and
display the colour selected. To change colour again, press and hold the button. To use the Nightlight without
monitoring, please refer to the ‘Independent Nightlight, Timer and Temperature Display’ section within this booklet.
Alternatively, to turn OFF the Nightlight, press the
button while in one-colour mode.
To extend the Baby Unit’s battery life, the Nightlight will only operate for 5 minutes at a time. For unlimited use,
switch to mains power using the adaptor provided.
• FEATURES AND FUNCTIONS
GBGB
1. Belt Clip
2. Wall Mount
4 5
