Operation and Storage Manual of Panel Heater 3English

• Position the panel heater with installed feet on the floor and before

connecting it to the power socket check if all instructions from the

very beginning of this manual have been followed correctly (Important

instructions and safety measures). The correct position is – the control

panel should be at the top of the appliance and the feet – on the floor!

BATHROOM OPERATION

• The panel heater must be installed in accordance with the normal trade

practices and in compliance with the national legislation (EU electricity

directives and regulations concerning special installations and places of

operation including bathrooms, shower cabins HD60364-7-701(IEC 60364-

7-701:2006)).

• In case this panel heater is to be used in a bathroom or other similar room,

the following installation requirements must be observed: the panel

heater is with IP24 protection (water drops protection). Hence it can be

installed in “Volume 2” (see the diagram below) in order to avoid the risk of

the control board (power switch and thermo regulator) being reached by

a person who is in a shower or a bathtub. The minimum distance between

the appliance and a water source should be not less than 1 meter! If you do

not feel sure about the installation of this panel heater in a bathroom, we

recommend you to consult a professional electrician.

Note: If the above-mentioned instructions cannot be implemented, it is

recommended to install the appliance in “VOLUME 3”.

• In wet premises the power source must be installed at a height of at least

25 cm above the floor (bathrooms and kitchens).

• The installation must be equipped with a safety fuse, and the distance

between the fuse contacts in disconnected condition should be at least 3 mm.

Thank you for choosing CN03 panel heater. This is a product providing heating in

winter depending on the consumers’ needs for comfortable room temperature.

If operated and taken care of properly in accordance with these instructions, the

appliance will provide you with many years of useful operation.

OPERATION INSTRUCTIONS

MECHANICAL CONTROL

Operation modes

Turn the panel heater on by pushing the switch in position “I” (turned-on), then

turn the regulator to the desired level (1 to 6) as you take into account the

following relation between the power levels:

* – anti-freezing mode/ enabled when room temperature falls below 5°C

1 / 2 – economy mode/ it maintains low room temperature/ this mode is

recommended to be used at night and when there are no people present in

the room. This mode permits to maintain the set room temperature while

saving energy.

3 / 4 / 5 – comfort mode/ it maintains moderate room temperature/ this mode

is recommended to be used to maintain relatively high comfortable room

temperature during the day.

6 – maximum power mode / it maintains HIGH room temperature/ this mode is

recommended to be used when you need maximum high room temperature

Important: Thermo Regulator digits do not correspond to certain room

temperature levels, but they can be used by users to memorize the relation

between room temperature and the thermo regulator settings.

When the room temperature is lower than the temperature that you have set

by the thermo regulator, the panel heater starts its operation and will operate

until the room temperature reaches the set temperature level of the unit.

When the room temperature is higher than the adjusted temperature of the

appliance, the panel heater will automatically go into “Stand by” mode.

PROTECTION

• The appliance is

equipped with a safety thermo turn-off device, which

automatically turns the heater off in cases of extreme temperature of the

panel heater /i.e. overheating of the appliance/.

• The safety thermo tur

n-off device will automatically restore the heater

operation when the temperature of the appliance falls below the

permissible ultimate values.

TIP-OVER PROTECTION

This heater is protected with a safety switch that turns off the appliance

automatically when the heater falls over, or is at an excessive angle from the

horizontal. This helps prevent accidents, and the heater will back to last set

mode when it is put back upright.

CLEANING

• It is compulsory first to turn off the appliance through its power

switch and to disconnect it from the power socket. Before starting the

cleaning session you should wait until the panel heater cools down in a

disconnected state.

• Clean the heater body with damp cloth, vacuum cleaner or a brush.

• Never immerse the appliance into water – there is danger for your life from

electric shock!

• Never use gasoline, thinner or hard abrasive products to clean the

appliance, because they will damage the appliance coating.

STORAGE

• Before putting the panel heater away let it cool down after you have

disconnected it from the power socket

• Use the appliance original packing to store it, if the panel heater will not

be in use for a long period of time. By storing the product in its original

packing you protect it from excessive dirt and dust accumulation.

• Never put a hot panel heater in its packing!

• It is necessary the product to be stored at a dry and dark place, protected

from direct sun light.

• It is explicitly forbidden to store the panel heater in damp and wet premises.

MAINTENANCE OPERATIONS OF THE APPLIANCE

• In case of appliance malfunction, please contact the authorized service

center closest to your location. /service centers are indicated in appliance

warranty documents/.
