Bedienungsanleitung

In the call log, new entries are marked with G. After querying the details or callback,

the entries are marked with H.

Received calls are displayed without marking.

Caller list features

1. In idle state press the menu key .

2. Select Call log and press .

3. Select the desired entry with and .

-Make a call: Press to dial the telephone number.

-Save to phonebook: Press , select Store number and press . Enter a

name and press . Edit the telephone number if necessary and press . Se-

lect a call group to assign the new entry to, and press .

-Details: Press , select Details and press . You will receive information

about the date and time of the call.

-Delete: Press , select Delete or Delete all and press .

Confirm the following query with .

Setting the call log type

1. In idle state press the menu key .

2. Select Call log and press .

3. Press , select Call log type and press .

4. Select All calls or Missed calls and press .

Chain dialling

1. Press the menu key whilst in a call .

2. Select Phonebook, Redial log or Call log and press .

3. Select the desired entry and press to dial the telephone number.

Find handset

Start paging

Press the paging button on the base unit to page all registered cordless handsets.

Stop paging

On the base unit: press the paging button again.

On the cordless handset: press any key, or place the handset in the base

unit/charger.

Join a call in progress

You can join a call already in progress on another device from up to 2 cordless hand-

sets.

1. Press to join the call.

2. Press or place the handset in the base unit/charger to exit the call.

Internal call

1. Press .

If only 2 devices are available the second one will ring right away. If there are several

registered cordless handsets, choose one and press .

Phonebook

The phonebook stores up to 100 entries.

You can find a phonebook entry by entering the first letter of the stored name using the

numeric keys. If necessary, use the arrow keys to select the desired entry.

You can assign your phone book entries to a specific call group. You can set different

ring melodies for these call groups.

Create a new entry

1. In idle state press .

2. Press .

3. Select New entry and press .

4. Enter the name and press .

5. Enter the telephone number and press .

6. Select one of the call groups to which you want to assign the new entry and press

.

Using the phonebook

1. Open the phonebook ( ) and select the entry with and .

-Make a call: Press

.

-Edit an entry: Press , select Edit and press . Edit the name if necessary

and press . Edit the telephone number if necessary and press . Edit the

call group if necessary and press .

-View an entry: Press , select View and press . Press and to view

the details.

-Delete: Press , select Delete or Delete all and press .

Confirm the following query with .

-Check capacity: Press , select Capacity and press . You will see the

number of entries, for example “1 / 100“. That means 1 entry stored of 100 entries

in total.

-Edit call groups

: Press , select Edit group and press .

Select a call group and press . Select Rename group and press , to edit

the name of the call group

- or -

Select Set ringtone and press , to edit the ringtone for the call group.

-Set speed dial

: Press , select Speed dial and press . Press the key, you

want to assign the entry to, and press .

To dial with speed dialing, press and hold down the relevant key for approx. 3 s.

2

1

3

4

5

12

13

11

6

8

7

9

10

1

2

3

4

5

5

8

76

Handset

1 Incoming call light

- Flashes when there is an incoming call.

2 Earpiece

3 Boost key

- To increase the volume in the handset. Press briefly during a call to switch the am-

plification on - pressing again switches the amplification off again.

If the amplifier function is activated, "Boost on" appears on the display and the in-

coming call light (1) lights up.

4 Direct call keys M1/M2/M3

- In idle mode, press to dial the stored number.

5 MENU/OK

- In idle mode: Press to access the main menu

- In sub-menu mode: Press to confirm the selection

- During a call: Press to access Phonebook/ Redial List/ Call List

6 Phonebook/Up

- In idle mode: Press to access the phonebook.

- In Menu/in lists: Press to scroll up.

- During a call: Press to increase the volume.

- In ringing: Press to increase the ringer volume.

7 Call/Hands-free

- In idle mode: Press to make or answer a call.

- In Redial list / Call List / Phonebook entry: Press to make a call to the selected

entry in the list.

- Whilst in a call: switch hands-free on/off.

8 Redial/Down

- In idle mode: press to open redial list.

- In Menu/in lists: Press to scroll down.

- During a call: Press to decrease the volume.

- In ringing: Press to decrease the ringer volume.

9 Alphanumeric keypad

- Press to enter numbers or characters/*/#.

- Key 0 during entering numbers: Long press to enter a dialling pause (P).

- Star key in idle mode: Long press to activate/deactivate key lock.

To switch between upper case and lower case while entering characters.

- Hash key in idle mode: Long press to switch handset ringer on/off.

Whilst in a call: Long press to enter flash function to use network features. In calls

list: Press to review caller’s number (if applicable).

10 Microphone

11 Volume keys

- Press to adjust the listening volume during a call.

12 CLEAR/BACK/MUTE/INT

- In Menu: Press to go back to previous level. Press and hold to go back to idle

screen.

- In editing / predialing mode: Press to clear a character / digit. Press and hold to de-

lete all the characters / digits.

- Press to mute the microphone during a call.

- In idle mode: Press to intercom another handset (only if more than one handset is

registered at the base station).

13 End call/Cancel

- Press to hang up during a call.

- Press to cancel an operation/return to idle mode while in a menu.

- Press and hold to switch off the handset when idle.

Base station

1 Loudspeaker

2 Playback/stop key (answering machine)

3 Delete key (answering machine)

4 LED indicator

- On when the answering machine (TAM) is on.

- Flashes when there are new memos or messages in the answering machine.

5 LED indicator

- On when a call is in progress.

- Flashes when there is an incoming call.

6 Phone line jack

7 Power supply jack

8 Page key

- Press to page all handsets when in idle.

Location

Place the base unit near a mains socket and a telephone wall jack to ensure that the con-

nection cables are long enough. Keep the unit approx. 1 m away from other electronic de-

vices to prevent interference. The base unit uses radio signals to connect with the cordless

handset. Signal strength depends on the base unit's location. The maximum range is 300 m

based on an unobstructed line of sight; the range is shorter inside buildings because of

walls and other obstacles.

Connect the base unit

1. Plug the connector on the cable end into the corresponding jack on the rear side of the

base and plug the power adaptor into the wall socket.

2. Plug the small connector on the end of the telephone line cord into the corresponding

jack on the base and plug the other end into the tele-

phone jack.

Note: Guide the power adapter cable through the

strain-relief tab on the base.

Important: Use only the power adaptors, telephone

line cord and batteries supplied with your phone,

otherwise your phone may not work.

Do not block access to the wall power supply with

furniture or other items.

Connect the cordless handset

1. Open the battery compartment and insert the re-

chargeable batteries. Observe the correct polarity.

2. Slide the battery compartment cover towards the

centre of the handset until it clicks into place.

For a full charge, the handset must be left in the base

unit for at least 16 hours (check the base unit’s power

supply!).

Important: Use only the batteries supplied with this product.

If the batteries need to be replaced later on the same battery type must be used.

Display icons

Battery is low; place handset in charger to recharge.

Full battery power level.

The handset speakerphone is in use.

Ringer off.

Keyboard locked.

Alarm activated.

Navigating the menu

1. Press .

2. Use and to select the desired menu item and press .

3. Press to cancel an operation, back up to the previous menu, or exit that menu.

4. Press to return to idle state.

Note: If a key is not pressed within 30 seconds, the telephone

automatically returns to idle mode.

Initial setup

1. “Pls set date/time“ appears in the display.

2. Press .

3. Use and

to select “Enter time“ and press .

4. Enter the time and press .

5. Use and

to select “Enter date“ and press .

6. Enter the date and press .

7. Press .

Menu layout

Call log Details

Delete

Delete all

Call

Store number

Call log type

Sound Ringer External Melody ...

Internal Melody ...

Ringer volume Level ...

Silent Beep/Off

Tones Key beep

Confirmation

Battery low

No coverage

Settings Handset settings Select base

Display Contrast

Handset name

Language

Auto answer

Register handset

Deregister

Handset reset

Base settings Ringer Ringtone

Ringer volume

Dial mode Tone/Pulse

Flash time 100/300/600 ms

System PIN

Base reset

Date/Time/Alarm Date/Time Time format

Date format

Enter time

Enter date

Alarm Alarm On/Off

Enter time

Ringtone

Memory keys M1/M2/M3/M4

Answer machine Play messages

Delete messages

Answer On/Off

Record MEMO

Outgoing message Record message Answer/Record

Answer only

Play message Answer/Record

Answer only

Answer settings Answer mode Answer/Record

Answer only

TAM language Deutsch/English/

Français

Answer delay 2/4/6/8 rings

Recording time 30/60/120 s / Unlimited

Call screening

Remote access Enable/Disable

Making and receiving calls

Making a call, answering a call, ending a call

To make a call

Enter the telephone number and press .

- or -

Press . When you hear a dial tone, enter the telephone number.

To answer a call

Press .

To end a call

Press or place the handset in the base station.

Handsfree

Whilst in a call press . To deactivate, press the same key again.

Volume control

Whilst in a call press the volume buttons on the side.

Mute

Whilst in a call press . Press again to resume the conversation.

Redial

1. Press in idle state.

2. Select the desired entry with and .

3. Press to dial the telephone number.

Call log

Note: This function is only available if your telephone service provider has activated

the CLIP (Calling Line Identification Presentation) service attribute. Please contact

your service provider for more information.

You can determine whether all calls are recorded or only calls that were not accepted.

Missed calls are indicated on the display.

D150 (1 handset)

D152 (2 handsets)

ENGLISH

Bewertung

Mehr zu diesem Bedienungsanleitung

Wir verstehen, dass es schön ist, ein gedrucktes Bedienungsanleitung für Ihr Switel D150 Schnurlose telefon zu haben. Sie können das Bedienungsanleitung jederzeit von unserer Website herunterladen und selbst ausdrucken. Wenn Sie ein Originalhandbuch wünschen, empfehlen wir Ihnen, Switel zu kontaktieren. Möglicherweise können sie ein Originalhandbuch bereitstellen. Suchen Sie das Bedienungsanleitung Ihres Switel D150 Schnurlose telefon in einer anderen Sprache? Wählen Sie auf unserer Homepage Ihre bevorzugte Sprache und suchen Sie nach der Modellnummer, um zu sehen, ob wir sie verfügbar haben.

Spezifikationen

Alle Anleitungen für Switel Schnurlose telefone
Weitere Anleitungen von Schnurlose telefone

Häufig gestellte Fragen zu Switel D150 Schnurlose telefon

Unser Support-Team sucht nach nützlichen Produktinformationen und beantwortet Ihre häufig gestellten Fragen. Sollte Ihnen ein Fehler bei den häufig gestellten Fragen auffallen, teilen Sie uns dies bitte anhand unseres Kontaktformulars mit.

Verwandte Produkte

Bedienungsanleitung

Switel DF1851 Schnurlose telefon

Bedienungsanleitung

Switel D112 Schnurlose telefon

Bedienungsanleitung

Switel E1503 Schnurlose telefon

Bedienungsanleitung

Switel D7010 Vita Plus Schnurlose telefon

Bedienungsanleitung

Switel DE2031B Schnurlose telefon

Bedienungsanleitung

Switel D7000 Vita Plus Schnurlose telefon

Bedienungsanleitung

Switel DC561 Schnurlose telefon

Bedienungsanleitung

Switel DF1853 Schnurlose telefon

Verwandte Kategorien
