USER GUIDE

The SUPERTOOTH D4 is a portable, wireless, rechargeable stereo speaker

featuring the convenience of NFC technology for instant pairing to a compatible

mobile device.

Users can stream music wirelessly from any cell phone, tablet, computer, laptop

or Mp3 player supporting Bluetooth A2DP.

The SUPERTOOTH D4 kicks out 8 watts RMS audio power and has a high

The integrated rechargeable batteries ensure 2 to 3 hours of non-stop,

maximum-volume music, and up to 12 hours of moderately played melodies.

pairing code

0 0 0 0

SUPERTOOTH D4 - NFC pairing *

1. Turn “ON” the D4

2. Place and maintain your NFC supported phone on top of the speaker (see image

above).

3. The speaker will go to pairing mode (a pairing beep will be heard on the speaker and

the LED Indicator (2) will turn red / blue alternately) and your phone will prompt for

pairing connection.

remove your phone from the speaker.

5. Pairing is successful if the LED Indicator (2) blinks blue every 3 seconds.

6. The D4 is now ready to use with your phone.

(*) Please make sure your phone supports NFC to pair it this way with the D4. If it doesn’t, please refer to Standard

pairing section below. For further information please visit : http://nfc-forum.org/

SUPERTOOTH D4 - Standard pairing

1. Put the D4 in pairing mode by pressing the MFB Button (1) until a pairing beep is heard

on the speaker and the LED Indicator (2) turns red / blue alternately.

2. While the D4 is in pairing mode, access the Bluetooth menu of your phone / device.

your phone / device’s manual).

3. When the phone / device displays the list of Bluetooth devices, select DISCO4.

4. If the phone / device asks for the password / pin code, enter 0000 and press OK.

5. Pairing is successful if the LED Indicator (2) blinks blue every 3 seconds.

6. The D4 is now ready to use with your phone / device.

SUPERTOOTH D4 - Button functions

Rear view of the SUPERTOOTH D4

(1) MFB Button

• From Off, press for 3 seconds to power On

• From On, press for 3 seconds to power Off

• From Off, press for 8 seconds to go to pairing mode

• From On, press for 5 seconds to go to pairing mode

• Short press to reconnect to the last paired phone / device

• From pairing mode, double press to clear the pairing list

(2) LED Indicator

• Steady red: charging

• Steady green : battery full

• Blinking red / blue : in pairing mode

• Blinking blue every 3 seconds : connected

• Blinking green : disconnected

• Blinking violet : erasing pairing list

(3) Charge Port (micro USB)

(4) Stereo Line Input

• 3.5 mm Jack connection

(1) (2) (3) (4)

Pairing code

0 0 0 0

Bluetooth Compliance :

- Stereo music streaming

- NFC

Operating Range :

10 meters Bluetooth standard

Frequency :

2.4 GHZ

Battery and Battery Life :

- Battery type : Lithium-Ion Power pack

- Music playing time (maximum volume level) : 2 to 3 hours

- Music playing time (medium volume) : 12 hours

- Stand-by time : 1500 hours

- Charging time : 2 hours

Audio Features :

- 8 Watts RMS power

- Compatible with any Bluetooth A2DP phone, PC, latop, tablet or Mp3 player

- Jack 3.5 auxiliary input for non Bluetooth A2DP Mp3 players, iPods or computers

- Wireless Play / Pause (AVRCP standard)

Multipairing :

- Maximum 8 phones paired

- 1 phone connected at a time

Federal Communications Commission (FCC) Statement

Industry Canada (IC) Statement

15.21

could void the user’s authority to operate the equipment.

15.105(b)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

part 15 of the FCC/IC rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipmen

following measures :

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Consult the dealer or an experienced radio/TV technician for help.

This device complies with part 15 of the FCC rules and Industry Canada licence-exempt RSS standard(s)

Operation is subject to the following two conditions :

1) This device may not cause interference and

2) This device must accept any interference, including interference that may cause undesired operation of the

device.

FCC/IC RF Radiation Exposure Statement :

This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment. End

users must follow the

must not be co-located or operating in conjunction with any other antenna or transmitter.

For the whole declaration please visit : http://www.supertooth.net/download

Euro Communication Equipements SAS

Route de Foix D117

11500 NEBIAS (FRANCE)

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such

marks by Euro-CB is under license. Other trademarks and trade names are those of their respective owners.

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection

systems). This marking shown on the product or its literature, indicates that it should not be

disposed with other household wastes at the end of its working life. To prevent possible harm to

the environment or human health from uncontrolled waste disposal, please separate this from other

types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local

recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract.

This product should not be mixed with other commercial wastes for disposal.

This product has an embedded, non-replaceable battery, do not attempt to open the product or remove

the battery as this may cause injury and damage the product. Please contact the local recycling facility for

removal of the battery. The embedded, non-replaceable battery is designed to last the life time of the

product.

Hereby, EURO COMMUNICATION EQUIPEMENTS, represented by Xavier MARCHANT, CEO, declares that

the SUPERTOOTH D4, MODEL BTD4, is in compliance with the essential requirements and other relevant

provisions of Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio

equipment and telecommunications terminal equipment and the mutual recognition of their

conformity.

Size and Weight :

- Height : 126 mm

- Width : 159 mm

- Depth : 120 mm

- Weight : 504 g

Accessories :

- USB to micro-USB cable

- 3.5 mm stereo jack cable
