5

ENGLISH

• POWERFUL AND QUIET operations can not be

activated at the same time.

TO SELECT FAN SPEED (5 OPTIONS)

• For AUTO, the indoor fan speed is automatically

adjusted according to the operation mode.

TO ADJUST VERTICAL AIRFLOW

DIRECTION (5 OPTIONS)

• Keeps the room ventilated.

•

If AUTO is set, the louvers swing up/down automatically

.

• In heat mode, the air blows at upper direction for a

while at the beginning, then starts to blow downwards.

TO SWITCH AMONG POWERFUL , QUIET

AND NORMAL OPERATION MODE.

POWERFUL: TO ACHIEVE TEMPERATURE QUICKLY

• This setting enables the desired set temperature to be

reached quickly.

Normal

QUIET : TO ENJOY QUIET ENVIRONMENT

• This setting provides a quiet environment by reducing

the airow noise.

OPTIONAL SETTINGS

RESETRESET

Press to restore the remote control's default setting.

ERRORERROR RESETRESET

Not used in normal operations.

Set the temperature 1°C higher in cool mode or 2°C

lower in heat mode than the desired temperature to

achieve a 10% power saving.

Use curtains to screen off sunlight and outdoor heat to

reduce power consumption during cool mode.

TO SET THE TIMER

• When you want the air conditioner to turn ON or OFF automatically.

DELAY OFF-TIMER

For example, to stop the air conditioner 5 hours later.

1 To select the Delay OFF-TIMER, press the

button once.

2 Press the button

to select the delay hour.

• The OFF-TIMER can only be set while the air-conditioner is in

operation.

DELAY ON-TIMER

For example, to start the air conditioner 2 hours later.

1 To select the Delay ON-TIMER, press the

button once.

2 Press the button

to select the delay hour.

• The ON-TIMER can only be set while the air-conditioner is not in

operation.

DELAY OFF AND ON TIMER

For example, to stop the air conditioner 3 hours later and start 4 hours

later.

1 To select the Delay OFF and ON Timer, press the button

2

times.

2 Press the button

to select the delay hour for OFF Timer.

3 Press the button

to select the delay hour for ON Timer.

• This mode of timer can only be set while the air-conditioner is in

operation.

DELAY ON AND OFF TIMER

For example, to start the air conditioner 7 hours later and stop 10

hours later.

1 To select the Delay ON and OFF Timer, press the button

2

times.

2 Press the button

to select the delay hour for ON Timer.

3 Press the button

to select delay hour for OFF Timer.

• This mode of timer can only be set while the air-conditioner is not in

operation.

TO CONFIRM THE TIMER SETTING

Press the

button once to activate the timer operation which

will start when the set time is reached.

TO CANCEL THE TIMER SETTING

Press the button again to cancel the timer operation.

• The timer indicator of the indoor unit will light up during the timer

operation.

• When ON Timer is set, the unit may start earlier before the

actual set time in order to achieve the desired temperature on

time.

• If you press operation

button during the timer setting

operation, timer setting will be cancelled.

• When a power failure occurs, the timer setting will be cancelled.

Once power is resumed, reset the timer.

TO SELECT OPERATION MODE

AUTO mode - For your convenience

• To set the temperature by pressing

or .

• During Automatic Operation, the operation mode will

be selected automatically in accordance with the

room temperature, outdoor air temperature and set

temperature of remote control.

•

The operation mode changes every half hour if necessary.

36

32

25

18

16

13 19 21 23 25

HEAT DRY COOL

Room Temperature

(Example) Setting Temp at 25

Outdoor Temperature

22

HEAT mode - To enjoy warm air

• Unit takes a while to warm up.

COOL mode - To enjoy cool air

DRY mode - To dehumidify the environment

•

Unit operates at low fan speed to give a gentle cooling operation.
