Bedienungsanleitung Marshall MG10 Gitarrenverstärker

Bedienungsanleitung

MG10

12 4563 1311 12

1

ENGLISH

1. Input Jack Socket

Jack input for your guitar. Use a good quality guitar cable

(i.e. one that’s screened/shielded) to help prevent noise,

interference and unwanted feedback.

2. Volume Control - Clean Channel

This control adjusts the volume of the Clean Channel.

3. Channel Switch

This switch allows you to change between the amp’s two

channels, Clean and Overdrive, via the front panel. When

the LED is green, the Clean channel is engaged. When

the LED is red, the Overdrive channel is engaged.

4. Gain Control - Overdrive Channel

This control sets the operating level of the pre-amp.

Simply turn up the Gain control until the required amount

of distortion is achieved.

5. Volume Control - Overdrive Channel

This control adjusts the volume of the Overdrive channel.

The louder this channel is set, the ‘looser’ the amplifier

will sound and feel.

6. Contour Control (MG10 only)

This highly effective tone control works by modifying the

mid-range (body). The tone can range from traditional

and woody sounding (setting at 10), to balls-to-the-wall

(setting at midway), to aggressive, ‘scooped’ and modern

(setting at 0)… and all points in-between.

7. Bass Control (MG15 & MG15R only)

Turning the Bass control will effect the amount of low

frequencies or bottom end in your guitar tone. Rotating

this clockwise will increase the amount of lower tones

creating deeper and thicker sounds. Turning this control

anti-clockwise will decrease the bass frequencies in your

tone reducing any bottom end thud.

8. Middle Control (MG15 & MG15R only)

Adjusting the middle frequencies will vary the amount of

body to your sound. Attenuating (decreasing) the middle

by turning this control anticlockwise will yield a more

hollow sound with the bass and treble frequencies

appearing to be more accentuated. Conversely,

increasing the middle will add body to the sound.

9. Treble Control (MG15 & MG15R only)

By adjusting the Treble control you can add or take away

the higher frequencies in your guitar tone. By increasing

the amount of treble you will make your tone brighter,

ideal for more percussive playing styles.

10. Reverb Control (MG15R only)

This control lets you add a lush reverb to the selected

channel, from a subtle hint to cavernous and all points

in-between.

11. MP3 Line In Socket

If you want to jam to your favourite MP3, CD or tape

track, merely connect the line out or headphone output of

your player here, adjust the volume of your player to

match that of your guitar and you’ve got the perfect ‘play-

along’ practice system.

12. Headphones Socket

For use when silent practice is the order of the day.

Connection of headphones will automatically mute the

internal speaker.

13. Power Switch

The power switch turns your amplifier on and off. The

Channel switch will light up when your amplifier is turned

on and will not be lit when the amplifier is switched off.

Note: The specific mains input voltage rating that your

amplifier has been built for is shown on the back panel.

Before connecting to the mains electricity supply, always

ensure that your amplifier is compatible with your

electricity supply. If you have any doubt, please get

advice from a qualified technician. Your Marshall dealer

will help you in this respect.

Please ensure the amplifier is switched off and

unplugged from the mains electricity supply before being

moved.

MG10 MG15 MG15R

Power (RMS) 10W 15W 15W

Channels 22 2

Speaker 1x6½" 1x8" 1x8"

Weight (kg) 4.8 7.4 7.4

Size (mm)

W 296 382 382

H314379 379

D175 205 205

Technical Specification

MG15 & MG15R

1 245789 1210 113 13
