KSC-4210User Manual

EN

Install the long spray nozzle (12) or extended connecting spray nozzle (13). Hold the

pipe section of the long spray nozzle in your hand, align the arrow with the single-line

mark on the short spray nozzle (2) on the machine body, and insert the long spray

nozzle in position. Rotate the long spray nozzle in clockwise direction, and align the

arrow on the long spray nozzle with the double-line mark on the short spray nozzle

on the machine body, as shown in figure (I). To remove the long spray nozzle, please

rotate the long spray nozzle inversely (counter clockwise) as shown in figure (II), and

align the arrow on the spray nozzle with the single-line mark on the machine body.

Then the long spray nozzle can be pulled out. For the extended connecting spray the

nozzle (13) you have to use the same procedure as shown above. Install the spray with

round brush (10) or bent spray nozzle (11) For direct installation on short spray nozzle

(2), aim the spray nozzle with round brush or bent spray nozzle at the top of spray

nozzle, as shown in figure (III), and push the spray nozzle upwards until it is in position.

Installation of the spray nozzle for door/window (14 & 15) First install the general spray

nozzle (14) on short spray nozzle (2), as shown in figure (IV) Install the two small hooks of the spray nozzle for door/

window (15) onto suspension lugs of the general spray nozzle, and then trigger the big hook of the spray nozzle for

door/window, and push the spray nozzle for door/window up and clutch (V) it onto the body of the general spray

nozzle.

• Disinfection and sterilization:

Install the long spray nozzle (12) on the short spray nozzle (2) and aim the spray nozzle at the position that needs

disinfection, then press down the steam button. High-temperature steam can kill bacteria.

• Cleaning the clothes:

Install the general spray nozzle (14) on the short spray nozzle (2), and then mount the towel sleeve (16). Aim it at the

hung clothes, and press down the steam button and move the general spray nozzle up and down as well as to the left

and to the right at the same time. Then stains can be removed from the clothes.

• Cleaning doors and windows:

Install the general spray nozzle (14) on the short spray nozzle (2), and then install the spray nozzle for door/window

(15) on it. Aim this at the door/window, and press down the steam button and move it up and down as well as to the

left and to the right at the same time. Then stains can be removed from the door/window.

• Cleaning the floor boards:

Install the bent spray nozzle (11) or round spray nozzle (10) on the long spray nozzle (12). For spots on difficult places

you can also use the extended connecting spray nozzle (13) . Then aim it at the floor board, and press down the steam

button to remove the dirt and stains in wall corners and on the floor.

• Unplug the power cord and disconnect the power supply.

• Press down the steam button to release the pressure until no steam is injected out.

• Slowly unscrew the safety cap but do not remove it, and residual steam will be discharged slowly until no steam

comes out. Then make sure the machine cools down for about five minutes. Finally, completely remove the safety cap.

• Use the funnel and measuring cup to refill a suitable quantity of cold or hot water into the tank.

• Re-install the safety cap onto the machine body and tighten it in position.

INSTALLATION OF ACCESSORIES

USE

REFILL WATER DURING OPERATION

CLEANING AND MAINTENANCE

• When finished cleaning, unplug the power cord and disconnect the power supply.

• Press down the steam button to release the pressure until no steam is injected out.

• Slowly unscrew the safety cap but do not remove it, and residual steam will be discharged slowly until no steam

comes out. Then make sure the machine cools down for about five minutes. Finally, completely remove the safety cap.

• Empty the residual water in the tank and clean the external surface with a piece of dry cloth.

• Lastly, re-install the safety cap onto the machine body and tighten it in position.

GUIDELINES FOR PROTECTION OF THE ENVIRONMENT

This appliance should not be put into the domestic garbage at the end of its durability, but must be taken to a central point for the

recycling of electric and electronic domestic appliances. This symbol on the appliance, instruction manual and packaging puts your

attention to this important issue. The materials used in this appliance can be recycled. By recycling used domestic appliances you

contribute to foment the protection of our environment. Ask your local authorities for information regarding the point of recollection.
