INSTRUCTION MANUAL

InLine® WoodCharge - Organizer with integrated Qi charging

surface made of walnut wood

GENERAL INFORMATION

Validity:

These operating instructions apply to the following product:

• 33392Y InLine® WoodCharge - Organizer with integrated Qi charging surface

made of walnut wood

Manufacturer:

INTOS ELECTRONIC AG

Siemensstraße 11

D-35394 Giessen

service@inline-info.com

Date: May 2024

CONTENTS OF DELIVERY

• 1x InLine® WoodCharge

• 1x USB-C textile connection cable 1.8m

• 1x Instruction manual (German/English)

Check the contents of delivery for completeness. If individual components are mis-

sing, please contact your specialist dealer.

EXPLANATION OF WARNING SYMBOLS AND NOTES

INTENDED USE

The InLine® WoodCharge - Organizer with integrated Qi charging surface (marked

storage surface) made of walnut wood is used to charge Qi-enabled products.

In the 3 additional shelves you can store all other products typical for the desk,

as long as they fi t into the pre-marked shelf and do not damage the material or

surface.

1. Qi charging surface

2. Further storage surfaces without function

3. Connection type: USB-C

4. LED status display

NON-INTENDED USE

The following is considered improper use in the sense of foreseeable misuse:

• Do not open the housing of the InLine® WoodCharge - Organizer under any

circumstances.

• Only use the product in dry, closed rooms and do not expose it to direct sun-

light, extreme temperatures or moisture.

• Ensure that the device to be charged is positioned correctly, as its display will

indicate that the charging process has been activated.

APPLICATION

1. Plug in the InLine® WoodCharge - Organizer using the supplied cable. (Red and

blue LED fl ashes briefl y alternately)

2. Position your device to be charged in the area of the Qi charging zone. (Blue

LED fl ashes slowly. Attention! to the display of the product to be charged, the

activation is also visually confi rmed there.)

3. If there is a metallic foreign object in the charging zone, the LED fl ashes red and

the charging is not activated.

4. Always ensure that the connections are correctly seated.

TECHNICAL DATA / SPECIFICATIONS

• Input voltage: DC5V / 3.0A, DC9V / 2.0A, DC12V / 1.5A

• Wireless output: 5W / 7.5W / 10W / 15W

• Frequency: 110-205kHz

• Connection type: USB-C

• No. of coils: 3

• Charging distance: <= 8mm

• Conversion: >= 75%

• Dimensions: 267x145x15mm (WxLxH)

• Weight: 260g

• Rubber pads: Yes

• Status LED: Yes (Flashing red/blue: Connection complete, LED off: Standby,

Blue fl ashing light: charging active, Red fl ashing light: Foreign object detection,

no charging active)

MAINTENANCE AND CLEANING

Clean the product with a dry, velvety cloth. Do not use water or other cleaning fl uids

that could damage the electronics or the wood.

DISPOSAL

Electrical and electronic equipment and batteries must not be disposed of

with household waste. The consumer is legally obliged to return electrical

and electronic equipment and batteries at the end of their service life to the desig-

nated public collection points or to the point of sale.

DISCLAIMER

1st edition English 18/2024

Documentation © 2024 INTOS ELECTRONIC AG

All rights reserved. No part of this manual may be reproduced in any form or du-

plicated or processed using electronic, mechanical or chemical processes without

the written consent of the publisher. It is possible that this manual may still contain

typographical errors or misprints. However, the information in this manual is che-

cked regularly and corrections are made in the next edition. We accept no liability

for technical or printing errors and their consequences. All trademarks and indust-

rial property rights are recognised. Changes in the sense of technical progress can

be made without prior notice. Our products, including the packaging, are not toys

and may contain small parts and sharp objects.

Please keep away from children.

This symbol indicates information that contributes to better under-

standing.

Check the product for any damage, such as cracks in the housing, be-

fore use. If damage is evident, do not use the product! Please read the

operating instructions carefully before use! Only use in dry conditions.

SIMPLIFIED EC DECLARATION

OF CONFORMITY

hereby declares that this InLine® WoodCharge complies with all relevant provisi-

ons of the RED (2014/53/EU) and ROHS (2011/65/EU + 2015/863/EU) directives.

The complete part of the EU Declaration of Conformity is available at

the following internet address:

https://www.inline-info.com/en/downloadcenter

The Manufacturer / Importer:

INTOS ELECTRONIC AG

Siemensstrasse 11

35394 Giessen

Owner of the Trademark:

If your product does not connect to the loading area, please change the

position of the product to be charged (within the charging area), until the

charging symbol for your product is displayed.

1

2

2

2

3

4
