Bedienungsanleitung Hoover SSNV1400 011 Dampfreiniger

Bedienungsanleitung

2

GETTING TO KNOW YOUR CLEANER

A. ON/OFF & Mode Selector Switch

B. Dust Tank Latch

C. Dust Tank

D. Floor Head

E. Steam Indicator Lamp

F. Steam Adjust Button

G. Water Tank

H. Water Tank Latch

I. Cord Hook

J. Base Cover

K. Textile Pad

L. Carpet Glider

ASSEMBLING YOUR CLEANER

Remove all components from the packaging.

1. Remove bolt from handle and attach the handle to the cleaner main body.

2. Insert handle bolt and tighten to x. [1]

USING YOUR CLEANER

VACUUM MODE

1. Plug the cleaner into the mains power, select the vacuum mode on selector switch

and tilt handle back to activate. [2]

2. Move the cleaner slowly backwards and forwards paying particular attention to high

trafc areas.

3. Push handle upright to stop the vacuum function.

4. Remove plug and wrap cord around cord storage hook. Store cleaner in an upright position.

STEAM MODE

IMPORTANT: Always unplug the cleaner when adding water or changing a textile pad.

NOTE:

Always sweep or vacuum the oor prior to use to remove any loose dirt or debris.

IMPORTANT: Do not use the cleaner without a textile pad attached to the oor head.

NOTE: Do not use the carpet glider when cleaning hard oors.

1. Attach textile pad to the base cover, then x the base cover to main body. [3]

2. Remove the clean water tank from the cleaner main body.[4] Remove the cap and

ll tank with clean cold water,replace cap.[5] Do not add any chemicals,

detergents or perfumes to the clean water tank.

3. Re-t the clean water tank to the main body. [6]

4. Plug the cleaner into mains power ,select steam mode on selector switch [7] and tilt

handle back to activate.

5. The steam indicator lights will illuminate, push steam adjust button to select steam

rate.[8]

A light will indicate your choice, wait 30 seconds for the water to heat up and

steam to be ready.

6. Move cleaner back and foward paying particular attention to high trafc areas.

[9]

7. Push handle upright to stop steam.

REFRESHING CARPETS

NOT E: Always sweep or vacuum the oor prior to use to remove any loose dirt or debris.

IMPORTANT: Do not use the cleaner without a textile pad attached to the oor head.

1. Attach the carpet glider to the oor head.[10]

2. Plug the cleaner into mains power,select steam mode on selector switch [7] and tilt

handle back to activate.

3. The steam indicator lights will illuminate, push steam adjust button to select steam

rate.[8]

A light will indicate your choice, wait 30 seconds for the water to heat up and

steam to be ready.

4. Move cleaner back and foward paying particular attention to high trafc areas.

[11]

CLEANER MAINTENANCE

IMPORTANT: Always ensure the cleaner has fully cooled down before performing

any maintenance tasks.

Empty the water tank

1. Unplug the cleaner from the mains power and ensure the unit has cooled.

2. Remove the clean water tank from the main body of the cleaner.

3. Twist the cap anti-clockwise and remove.

4. Empty any excess water from the tank. [12] Replace the cap and return to the cleaner.

Removing and cleaning the textile pad

1. Unplug the cleaner from the mains power and ensure the unit has cooled.

2. If necessary remove the carpet glider, then peel the textile pad from the oor

base.[13] Wash the textile pad in a washing machine with a mild detergent at max

temperature 40°C.

IMPORTANT: Do not use bleach or fabric softener when washing the textile pad.

Empty the dust cup

1. Press the dust cup latch [14] and remove dust cup assemlby.Twist dust cup

cover counterclockwise to open. [15]

2 Tap canister gently over trash receptacle to empty. [16]

Empty the cone lter

1. Lift the lter frame out from the top of the dust cup and remove the lter layers from

the lter frame. [17]

2. Wash it in warm water [18], and allow it to dry [19] thoroughly before replacing to

the cleaner.

GB
