Bedienungsanleitung Hamax Outback Fahrradanhänger

Bedienungsanleitung

p. 13 p. 14

down.

• Insert the shoulder and waist belt buckles into the center buckle [16b] on the crotch strap [16d] until you feel it snap. Reduce

the length of the crotch strap, shoulder belts and the waist belts so that your child is securely tightened. Verify that the safety

harness is locked by pulling both shoulder and waist belts.

[17] Mounting the LED lights

• Place the lights on the side of the trailer that is most exposed to the road.

• Front: Aach the white LED light through the hole in the fabric.

• Rear: Aach the red LED light on the push bar at the back of the trailer.

NOTE: LED lights can be purchased at your bicycle specialist store. Make sure they comply with the lighting regulations in

your country.

CARE AND MAINTENANCE

Check before using the trailer

• The wheels are properly secured to the trailer.

• The tires are inflated according the specified tire pressure

• The trailer is unfolded properly and the mechanism is locked on both sides. Do not forget to lock the push bar.

• The seat back rest is well secured and tightened. Please see the maintenance section.

• The safety flag and lights are in place whenever required.

Storage

• It is highly recommended to store the Outback trailer indoors, in a dry and well-ventilated area out of direct sunlight.

TIP: There is a Hamax storage cover available for beer protection.

Maintenance

• Push bar: In case the push bar slips from its position, tighten the nut [18] under the fabric of the push bar. Make sure the nuts

are tightened equally on both sides.

• Parking brake [2m]: Adjust the parking brake cable by seing the cable adjuster [19] near the brake pedal.

• Safe connection point [2e]: If dirt is inside the safe connection point [2e], rinse it with water.

• Seat base back rest [2j]: Regularly tighten the straps [20] at the rear of the seat base back rest. Make sure that you start to

tighten it at the top and follow by tightening it at the boom.

• Do not use cleaning solvents. Clean only with mild soap and water.

• The seat paddings [2d] can be removed from the trailer for cleaning purposes. Wash seating by hand or using cold machine

wash with a short spin cycle.

• Allow the trailer to dry completely before storing it to prevent it from becoming moldy.

• If the trailer is involved in an accident or is damaged, contact your dealer to check if it can still be used.

WARRANTY

The Hamax Outback Multifunctional Child Carrier is warranted from the date of purchase. The warranty period depends on the

law of the country in question. The warranty applies to defects in materials or workmanship, and does not cover damage due

to improper use, lack of maintenance, failure to follow the user manual, use of force or normal wear and tear. The warranty is

valid for the original user only. Please read the use and maintenance recommendations carefully. Conditions that may cause

premature wear of the carrier may not be covered by the warranty. Should the carrier require service or you want to make a

warranty claim, please contact your local dealer from whom you purchased your carrier.

NO Takk for at du har valgt Hamax Outback sykkelvogn

Gratulerer med kjøpet av Hamax Outback sykkelvogn. Med denne kan du frakte barnet/barna på en trygg og komfortabel måte,

enten du bruker den som sykkelvogn, barnevogn eller jogger (tilbehør til jogger selges separat). Les bruksanvisningen nøye før du

monterer og bruker sykkelvognen. Vi ønsker deg og barna dine mange hyggelige turer!

Ta godt vare på bruksanvisningen for senere bruk.

Produktregistrering

Vi anbefaler at du registrerer di nye produkt. Det kan du gjøre her: www.hamax.com/product-registration

SPESIFIKASJONER

• Se spesifikasjonene i bilde [A]

• Dimensjon sammenlagt (inkl. hjulbeskyelse): 108 x 81 x 30 cm

• Tilhengervekt: 20 kg (montert tilhenger inkl. sykkelarm)

• **Du kan kontrollere belastningen på trekkstangen ved å måle vekten i enden av sykkelarmen når sykkelvognen er lastet

med passasjerer og bagasje. Du kan måle ved å stille deg på en vekt og trekke fra din egen vekt. Still deg på vekten og

hold sykkelarmen i hendene dine. Sørg for at du holder sykkelarmen i re høyde. Trekk fra din egen vekt og resultatet er

belastningen på trekkstangen.

95cm /

37.4in

109cm / 42.9in 86cm / 33.9in

30-40cm /

11.8-15.7in

65cm / 25.6in

51cm / 20in

Trekkhastighet

Anbefalt hastighet: 16 km/t

Makshastighet: 24 km/t

A

Vektkapasitet

Maks last: 40 kg

Barnets maksimale vekt: 22 kg

Maks vekt inkludert tilhenger: 60 kg

Trekkstangbelastning**

Min.: 0 kg

Maks.: 8 kg

Fysiske krav

Minste alder: 6 måneder

Barnets maksimale høyde: 117 cm

Seteposisjoner

For 1 eller 2 barn

30cm /

11.8in

30cm /

11.8in
