Operation

1.After unit starts, select your desired operation mode.

2.Press TIMER button to change TIMER mode. Every

time the button is pressed, display changes as follows:

Remote controller:

BLANK

TIMER ON TIMER OFF TIMER ON-OFF

Then select your desired TIMER mode (TIMER ON or

TIMER OFF or TIMER ON-OFF). " "or " "will flash.

3.Press / button to set time.

It can be adjusted within 24 hours.

Hints:

After replacing batteries or a power failure happens, time

setting should be reset.

According to the Time setting sequence of TIMER ON or

TIMER OFF, either Start-Stop or Stop-Start can be achieved.

Timer On/Off On-Off Operation

CE

All the products are in conformity with the following

European provision:

- Low Voltage Directive 73/23/EEC

- Low Voltage Directive 2006/95/EC

-Electomagnetic CompatibilitY 89/336/EEC

-Electomagnetic CompatibilitY 2004/108/EC

ROHS

The products are fulfilled with the requirements in the

directive 2002/95/EEC of the European parliament and of

council on the Restriction of the use of Certain Hazardous

Substances in Electrical and Electronic Equipment (EU

RoHS Directive)

WEEE

DISPOSAL REQUIREMENTS:

Your air conditioning product is marked with this

symbol.This means that electrical and electronic

products shall not be mixed with unsorted

household waste. Do not try to dismantle the

system yourself : the dismantling of the air

EUROPEAN REGULATIONS

CONFORMITY FOR THE MODELS

1

1+2=

kg

R410A

2

kg

2=

1=

B

C

D

F E

kg

A

This product contains fluorinated greenhouse gases covered by

the Kyoto Protocol. Do not vent into the atmosphere.

Refrigerant type:R410A

GWP* value:1975

GWP=global warming potential

Please fill in with indelible ink,

• 1 the factory refrigerant charge of the product

• 2 the additional refrigerant amount charged in the field and

• 1+2 the total refrigerant charge

on the refrigerant charge label supplied with the product.

The filled out label must be adhered in the proximity of the product

charging port (e.g. onto the inside of the stop value cover).

A contains fluorinated greenhouse gases covered by the Kyoto

Protocol

B factory refrigerant charge of the product: see unit name plate

C additional refrigerant amount charged in the field

D total refrigerant charge

E outdoor unit

F refrigerant cylinder and manifold for charging

IMPORTANT INFORMATION REGA-

RDING THE REFRIGERANT USED

In accordance with the directive 2002/96/CE of the European

parliament, herewith we inform the consumer about the dis-

posal requirements of the electrical and electronic products.

conditioning system,treatment of the refrigerant, of oil and of

other part must be done by a qualified installer in

accordance

with relevant local and national legislation. Air conditioners

must be treated at a specialized treatment facility for reuse,

recycling and recovery. By ensuring this product is disposed

of correctly, you will help to prevent potential negative cons-

equences for the environment and humen health. Please

contact the installer or local authority for more information.

Battery must be removed from the remote controller and dis-

posed of separately in accordance with relevant local and

nationl legislation.

Contains fluorinated greenhouse gases

covered by the Kyoto Protocol

Healthy airflow Operation

1.Press to starting

Setting the comfort work conditions.

2.The setting of healthy airflow function

Note:

1.After setting the healthy airflow function, the position

grill is fixed.

4.In cooling and dry, using the air conditioner for a long

time under the high air humidity, condensate water may

occur at the grille .

3.The cancel of the healthy airflow function

Notice: Do not direct the flap by hand. Otherwise, the

grille will run incorrectly. If the grille is not run correctly, stop

for a minute and then start, adjusting by remote

controller.

2.In heating, it is better to select the

3.In cooling, it is better to select the

mode.

mode.

TIMER OFF-ON

0.5h

0.5h 0.5h

0.5h

Press the button for each time, setting time in the first

12 hours increased by 0.5 hour every time, after 12

hours,increased by 1 hour every time.

Press the button for each time, settiing time in the first

12 hours decreased by 0.5 hour every time, after 12

hours,decreased by 1 hour every time.

After adjust the time,press button and confirm the

time ON or OFF button will not flash any more.

4.Confirm timer setting

5.Cancel timer setting

Press the timer button by times until the time display

eliminated.

Press button to enter additional options,Press this

button continuously, the louvers location will cycle between

in the following three locations, to choose the swing location

what you needed,and then press button to confirm.

Press button to enter additional options,Press this

button continuously, the louvers location will cycle between

in the following three locations again,and then press

button to cancel.

Healthy

airflow

upwarder

Healthy

airflow

downwarder

Present

position

4
