Bedienungsanleitung Florabest IAN 43526 Sonnenschirm

Bedienungsanleitung

4 GB

Q

Opening the umbrella top

j Push the arm

7

upwards until it meets the stopper

18

(see Figure E, step

1

). Lock the support rod

16

in place by pushing the plastic sleeve

17

downwards (see Figure E, step

2

).

j Push the handle

12

upwards until it meets the stopper

10

(see Figure F,

step

1

). Lock the handle

12

in place with the locking knob

11

. To do

this turn the locking knob

11

in the clockwise direction to tighten it (see

Figure F, step

2

).

j Turn the crank

14

clockwise until the umbrella top

8

is completely open

(see Figure G, step

1

).

Q

Turning the umbrella roof

j Release the lock on the handle

12

by turning the locking knob

11

anticlockwise until the handle

12

moves freely (see Figure G, step

2

).

j Swivel the umbrella top

8

into the desired position (see Figure G,

step

3

).

j Lock the handle

12

in place with the locking knob

11

. To do this turn the

locking knob

11

in the clockwise direction to tighten it (see Figure G,

step

4

).

Q

Inclining the umbrella top

j Release the lock on the handle

12

by turning the locking knob

11

anticlockwise until the handle

12

moves freely (see Figure H, step

1

).

j Push the handle

12

downwards until the desired inclination angle is

reached (see Figure H, step

2

).

j Lock the handle

12

in place with the locking knob

11

. To do this turn the

locking knob

11

in the clockwise direction to tighten it (see Figure H,

step

3

).

Q

Closing the umbrella top, moving the hanging

umbrella

j Turn the crank

14

anticlockwise until the umbrella top

8

is completely

closed (see Figure I, step

1

).

j Push the plastic sleeve

17

on the support rod

16

upwards (see Figure J,

step

1

).

j Pull the arm

7

on the crankcase

15

downwards (see Figure J, step

2

).

j Release the lock on the handle

12

by turning the locking knob

11

anticlockwise until the handle

12

moves freely (see Figure K, step

1

).

j Push the handle

12

downwards until it lies against the union nut

13

(see

Figure K, step

2

).

Q

Cleaning and maintenance

j Clean this product with a slightly dampened, lint-free cloth.

j Store the product in winter in a cool, dry place – avoid storing the

product in a heated room.

Q

Disposal

The packaging is made entirely of recyclable materials, which you

may dispose of at local recycling facilities.

Contact your local refuse disposal authority for more details of how to

dispose of your worn-out product.

Q

WARRANTY

The device has been manufactured to strict quality guidelines and

meticulously examined before delivery. In the event of product defects you

have legal rights against the retailer of this product. Your legal rights are not

limited in any way by our warranty detailed below.

The warranty for this device is 3 years from the date of purchase. Should this

device show any fault in materials or manufacture within three years from the

date of purchase, we will repair or replace it - at our choice - free of charge

to you.

The warranty period begins on the date of purchase. Please keep the

original sales receipt in a safe location. This document is required as your

proof of purchase. This warranty becomes void if the device has been

damaged or improperly used or maintained.

The warranty applies to faults in material or manufacture. This warranty does

not cover product parts subject to normal wear, thus possibly considered

consumables (e.g. batteries) or for damage to fragile parts, e.g. switches,

rechargeable batteries or glass parts.

REV_ 43526_HU_SI_CZ_SK.indd 4 9/27/2013 5:59:52 PM
