IMPORTANT SAFETY INSTRUCTIONS

The safety of electrical appliances from FIRST Austria

complies with the recognized technical directives and

legal regulations for safety. Nevertheless, you and

the other users of the appliance should observe the

following:

• Please read these instructions carefully before using

this appliance for the rst time and keep them for

further reference.

• This product has not been designed for any other

uses than those specied in this manual.

• Before connecting the appliance to the power

source, check if the voltage indicated on the

appliance corresponds with the mains voltage

in your home. If this is not the case, contact your

dealer and do not use the appliance.

• If the appliance is grounded (protection class I),

the wall outlet and any extension to which it is

connected must also be grounded.

• Do not let the cord touch hot surfaces.

• Do not leave the unit in a place near a heat source

such as a radiator or air duct, or in a location

exposed to direct sunlight, excessive dust,

mechanical vibration, or shock.

• Do not expose the unit to rain or other damp

conditions.

• If the appliance or the power cord shows any signs

of damage, do not operate it! Take the product

to an authorized and qualied service center for

inspection or repair.

• To protect from electrical hazard, do not immerse

this appliance or cordset in any liquids.

• The power outlet must be easily accessible at

all times to ensure that the unit can be quickly

disconnected from the mains.

• The ventilation openings must be kept free.

• This device is intended for home use only, do not

use it commercially.

• Do not use this appliance outdoors.

• Do not leave the appliance unattended when

plugged into a power outlet.

• Do not leave the appliance unattended while it is

operating.

• Vacuuming the following objects is prohibited,

otherwise damage to the vacuum cleaner or

accidents involving personal injury may occur:

- any liquids

- large or sharp shards (broken glass...)

- ammable or explosive substances such as

gasoline or alcohol

- burning or glowing objects (cigarettes, matches or

hot ashes)

• Never vacuum people and animals with the vacuum

cleaner.

• Always disconnect the appliance from power

after use, before cleaning and in the event of a

malfunction.

• Do not pull directly on the power cord, rather pull

on the plug to disconnect the appliance from the

power source.

• The appliance can be used by children aged from

8 years and above and persons with reduced

physical, sensory or mental capabilities or lack

of experience and knowledge if they have been

given supervision or instruction concerning use

of the appliance in a safe way and understand the

hazards involved. Children shall not play with the

appliance. Cleaning and user maintenance shall not

be made by children unless they are older than 8

and supervised. Keep the appliance and its cord out

of reach of children less than 8 years.

• We are excluded of liability for all damages that

may arise if the appliance is used for purposes

other than originally intended or if it is used

inappropriately.

• Repairs and other work undertaken on the unit

must only be done by authorised specialist

personnel!

SCOPE OF DELIVERY

• Vacuum cleaner

• Universal oor brush

• Crevice/brush nozzle

• Telescopic tube

• Instruction manual

PRODUCT OVERVIEW (see g. 1)

1. Universal oor brush

2. Crevice/brush nozzle

3. Telescopic tube

4. Airow regulator

5. Hose handle

6. Suction hose

7. Hose end

8. Dust container handle

9. Dust container release button

10. Cable rewind foot switch

11. ON/OFF foot switch

12. Power cable

13. Wheel

14. Air outlet lter (HEPA)

15. Air outlet cover

16. Air inlet lter (HEPA)

17. Filter basket

18. Dust container

19. Bottom lid of dust container

20. Latch (bottom lid)

21. Latch (top lid)

22. Top lid of dust container

ASSEMBLY

1. Connect the suction hose and the telescopic tube.

2. Adjust the telescopic tube to a suitable height by

pressing the locking button and pulling the tube

apart or pushing it together.

3. To connect the hose to the vacuum cleaner,

align the latching lug of the hose end

with the groove of the hose

connector, then push the hose

end in until it audibly snaps in

place.

4. To detach the hose, turn the hose end 90° in any

direction and pull it out.

5. Attach the desired cleaning accessory:

Universal oor brush

Position 1:

Brush extended

Position 2:

Brush retracted

Suitable for hard oors Suitable for carpets

Crevice/brush nozzle

For corners, edges or small spaces

OPERATION

1. Before use, make sure that the dust container is

inserted correctly.

2. Pull out the power cable until the yellow marking

becomes visible. If the red mark is visible, the cable

is completely unwound and further pulling may

damage the cable drum. Therefore, unwind the

cable carefully and slowly as soon as the yellow

marking can be seen.

3. Insert the power plug into the power outlet.

4. Press the ON/OFF foot switch to turn on the

vacuum cleaner.

5. To vacuum, pull or push the nozzle over the surface

to be cleaned.

6. If necessary, you can quickly reduce

the suction power by moving the

airow regulator on the hose handle.

This can be helpful when vacuuming

curtains. Slide it backwards to

reduce the suction power and

forwards to increase it.

7. After vacuuming, press the ON/OFF foot switch to

turn o the vacuum cleaner.

8. Unplug the power cord from the power outlet.

9. Press the cable rewind foot switch to wind up the

cord. Hold the cable with your hands while doing

this to prevent it from bouncing back and forth in

an uncontrolled manner.

CLEANING & MAINTENANCE

Your vacuum cleaner is quick and easy to clean and

maintain. Empty the dust container and clean the

lters regularly.

• Before cleaning, make sure that the appliance is

switches o and has been disconnected from the

mains.

• Never immerse the appliance or power cord in

water. Do not let the electrical parts come into

contact with moisture.

• Do not use harsh or corrosive cleaners or solvents.

• Clean the housing of the unit with a damp cloth

and then wipe it dry.

EMPTYING THE DUST CONTAINER (see g. 2)

Be careful not to inhale the dust when emptying, as

it could cause health problems or allergies.

① Press the dust container release button and pull the

dust container upwards by the handle.

② Open the latch of the bottom lid and empty the

dust container directly over a dustbin.

CLEANING THE AIR INLET / DUST FILTER (g. 3)

Do not operate the vacuum cleaner without a lter

or with a damaged lter, otherwise the vacuumed

dust will get into the room air and may cause health

problems or allergies. Replace a damaged lter

immediately.

① Open the latch of the top lid and pull the lter

basket upwards out of the dust container.

② Unlock the HEPA lter by turning it

counterclockwise. Pulling it out upwards.

③ Clean the lter basket from dust and rinse the HEPA

lter under running water. Then allow it to dry

completely.

④ Put the HEPA lter back into the lter basket and

lock it by turning it clockwise.

⑤ Place the lter basket back in the dust container.

Make sure that the latching lug of the lter basket is

aligned with the groove of the dust container.

CLEANING THE AIR OUTLET FILTER (g. 4)

The air outlet lter is located inside the wheel below

the ON/OFF foot switch.

① Turn the air outlet cover clockwise to open it and

remove the HEPA lter.

② In case of light soiling, it is sucient to tap out the

lter, in case of heavy soiling, clean the lter under

running water. Allow the lter to dry completely

before reinserting it.

③ Place the lter back into the unit and close the air

outlet cover by turning it counterclockwise until it

audibly snaps into place.
