ELECTRIC ROTARY HAMMER

DRILL

THE NUMBERS IN THE FOLLOWING TEXT

CORRESPOND WITH THE PICTURES AT PAGE 2

TECHNICAL SPECIFICATIONS

PRODUCT INFORMATION

Fig.A

1. Rotary stop selection lever

2. On-off Switch

3. Main handle

4. Hammer stop selection lever

5. Carbon brush cap

6. Electric cord

7. Auxiliary handle

8. Depth gauge

9. Dust cap

10. Drill

11. Locking sleeve

INTENDED USE

The Ferm FBH-620KS is intended to be used for drilling

holes in material like stone, concrete and similar

materials. With suitable drill bits the machine also can be

used to drill holes in wood or metal. The machine can be

used as a demolition hammer in combination with the

appropriate chisels. All other purposes are explicitly

excluded.

Check the machine and accessories for transport

damage.

SAFETY INSTRUCTIONS

The following symbols are used in these instructions for

use:

Denotes risk of personal injury, loss of life or

damage to the tool in case of non-observance of

the instructions in this manual.

Denotes risk of electric shock.

Carefully read this manual before using the machine.

Make sure that you know how the machine functions and

how to operate it. Maintain the machine in accordance

with the instructions to make sure it functions properly.

Keep this manual and the enclosed documentation with

the machine.

SPECIAL SAFETY INSTRUCTIONS

BEFORE USING THE APPLIANCE

• Examine the drilling surface for hidden electric

cables, gas pipes or other obstacles with e.g. metal

detector.

• Check the following points:

Does the voltage of the motor correspond with the

mains power supply?

Are the extension cable, cord insulation and plug in

good condition: sturdy, not loose or damaged?

Is there a good connection at the socket?

Is the drill running abnormally, overheating or

generating excessive sparks?

Should any of the above problems be observed cease

all further use and make immediate repairs.

ELECTRICAL SAFETY

Warning! When using electric tools, basic safety

precautions should always be followed to reduce the

risk of fire, electric shock and personal injury. Read

all these instructions before attempting to operate

this product and save these instructions.

Always check that the voltage corresponds to the

voltage on the rating plate.

The machine is double insulated in accordance with

EN50144; therefore no earth wire is required.

Replacing cables or plugs

Immediately throw away old cables or plugs when they

have been replaced by new ones. It is dangerous to insert

the plug of a loose cable in the wall outlet.

Using extension cables

Only use an approved extension cable suitable for the

power input of the machine. The minimum conductor

size is 1.5 mm

2

. When using a cable reel always unwind

the reel completely.

OPERATION

Hammer drilling requires low operator pressure.

An excess of pressure can cause the motor to be

unnecessarily overloaded.

MANUAL SIDE GRIP

The manual side grip can be rotated to either side of the

machine to ensure safe and comfortable operation for

both left and right-handed operators.

• Loosen the grip by turning anti-clockwise.

• Rotate the grip to the desired position.

Voltage | 230 V

~

Frequency | 50 Hz

Input power | 620 W

Speed, no load | 750/min

Impact rate | 2920/min

Max. drilling capacity concrete | Ø 26 mm

steel | Ø 13 mm

wood | Ø 40 mm

Weight | 5.2 kg

Lpa Sound pressure level | 94.0 dB(A)

Lwa Sound power level | 107.0 dB(A)

Vibration | 7.6 m/s

2

Ferm 3

SPARE PARTS LIST FBH-620KS

REF NR DESCRIPTION FERM NR

700150 CYLINDER 003

700151 HAMMER CYLINDER 005

700152 UMBRELLA GEAR (BIG) 010

700153 O-RING 011

700154 PISTON 012

700155 RECIPROCAL LEVEL 013

700156 BUSHING 014

700157 FRONT COVER 039

700158 SLEEVE 041

700159 HAMMER BLOCK 046

700160 UMBRELLA GEAR (SMALL) 050

806002 BALL BEARING 6002 ZZ 052

700161 SPECIAL NUT 058

800627 BALL BEARING 627 ZZ 059

700162 ECCENTRIC SHAFT 060

806202 BALL BEARING 6202 ZZ 062

700163 NO.1 GEAR 066

806001 BALL BEARING 6001 ZZ 071

700164 ROTOR 072

800608 BALL BEARING 608 ZZ 077

700165 BRUSH COVER 081

700166 CARBON BRUSH SET 082

700167 BRUSH HOLDER 083

700168 NEEDLE BEARING 088

700169 SWITCH 096

700170 DUST COVER 104

700171 DEPTH GAUGE 106

700172 HANDLE COMPLETE 107 T/M 111

700173 PIN 113

700174 STATOR 115
