Never apply any blades of which the thickness is gre-

ater than that of the riving knife.

5. Do not stop the blade of a circular saw by pressing the

blade from the side.

6. Check that the blade guard can freely move and fully

closes.

7. Never lock-up the guard in the open position.

8. Never put sideward pressure on the blade. This may

cause the blade to break.

9. Be careful when cutting wood with knots, nails or

cracks in it and/or dirt on it, as these can cause the

blade to get stuck.

10. Never leave the circular saw unattended.

11. Use this circular saw to saw only wood or wood-like

products.

USING THE MACHINE:

1. Use clamps or a vice to hold the work.

2. Never remove wood chips and saw dust that is close to

the saw blade with your hands. If there are small pie-

ces of wood left between the fixed and the movable

parts, the circular saw will have to be stopped. Plug

removed from the socket, before any piece left can be

removed.

3. Check that the blade is suitable for the spindle speed

of the circular saw. Do not attempt to cut before the cir-

cular saw has reached full speed. Make sure the circu-

lar saw runs without load (i.e. is not in contact with the

work) when you switch it on. The circular saw must

have reached its full speed first.

4. Never cut wood that is thicker than the depth of the

saw blade.

5. When cutting in wooden walls or floors, check there is

no wiring or piping where you intend to cut.

6. Switch off the tool and wait until the blade has stopped

completely before moving the saw away from the work

or putting it down. Hearing protection should be worn

when using circular saw.

SWITCH OFF THE MACHINE IMMEDIATELY WHEN

YOU DISCOVER:

1. A defective mains plug or mains lead;

2. A defective switch.

3. Overheating of the circular saw.

4. Smoke or odeur caused by scorched insulation.

ASSEMBLY AND ADJUSTING INSTRUC-

TIONS

Before adjusting the saw, make sure the plug is

removed from the socket.

ADJUSTING THE RIVING KNIFE.

Fig. B.

-Move the blade guard backwards and lock by means

of knob (1).

- Use a screwdriver to loosen both screws (2).

- Adjust the riving knife, referring to the distances indi-

cated in the drawing.

Retighten both screws (2) and release knob (1).

- Check that the riving knife is exactly behind the blade.

ADJUSTING THE CUTTING ANGLE.

Fig. C.

- Loosen both knobs (1).

- Move the shoe (2) into the proper position (0°- 45°).

The cutting angle is indicated by the pointer (3).

ADJUSTING THE DEPTH OF CUT.

Fig. D.

- Loosen knob (1).

- Move the shoe (2) downwards.

- The depth of cut can be checked (3).

-After adjustment retighten knob (1).

MOUNTING THE PARALLEL GUIDE.

Fig. E.

- Loosen knob (1).

- Insert the guide into the relevant recesses (2).

-t the required width and retighten knob (1).

REPLACING OR CLEANING THE BLADE

Fig. F.

-Move the blade guard backwards and lock by means

of knob (1).

- Lock-up the shaft with the spindle lock.

- Use an hexagonal key (2) to loosen the left-hand bolt

in the centre of the blade.

- Remove the blade and clean or replace it.

- Put the blade back in its proper position, making sure

the teeth of the blade point in the same direction as

those of the riving knife (4).

- Fit the locking ring (5) and retighten the left-hand bolt.

- Release knob (1) to put the guard back in place.

After fitting a new blade it may be necessary to

readjust the riving knife. (Fig. B)

REPLACING THE CARBON BRUSHES

Fig. G.

- Remove both screws (1).

- Take the brushes (2) out and check.

- Reinsert the brushes into the relevant recesses.

- Make sure the copper part of the brushes firmly tou-

4 Ferm

C

|

E

|

|

∆ΗΛΩΣΗ ΣΥΒΑΤΙΚΟΤΗΤΑΣ (

GR

)

∆ηλούµε υπευθύνωζ τι το προιν αντο είναι

κατασκευασµένο σύµφωνα µε τονζ εξήζ

Κανονισµούζ ή Κατασκεναστικεζ σνστάσειζ:

EN50144-1, EN50144-2-5,

EN55014-1, EN-55014-2,

EN61000-3-2, EN61000-3-3,

Κατά τιζ διατάξειζ των Κανονισµών τηζ Κοινήζ

Αγοράζ:

98/37/EEC

73/23/EEC

89/336/EEC

απ 01-10-2001

GENEMUIDEN NL

G.M. Ensing

Quality department

Ferm 65
