Bedienungsanleitung Fellowes Proteus A3 Laminiergerät

Bedienungsanleitung

3

CAPABILITIES

- Plug the machine into an easily accessible socket.

- To prevent electrical shock - do not use the appliance close to water, do not spill water on to the appliance, power cord or wall socket.

DO ensure the machine is on a stable surface.

DO test laminate scrap sheets and set the machine before final laminations.

DO remove staples and other metal articles prior to laminating.

DO keep the machine away from heat and water sources.

DO turn off the machine after each use.

DO unplug the machine when not in use for an extended period.

DO use pouches designed for use at the appropriate settings.

DO keep away from pets, while in use.

DO ensure self-adhesive pouches are only used with the cold setting.

DO NOT leave the power cord in contact with hot surfaces.

DO NOT leave power cord hanging from cupboards or shelves.

DO NOT use appliance if the power cord is damaged.

DO NOT attempt to open or otherwise repair the machine.

DO NOT exceed the machines quoted performance.

DO NOT allow children to use this machine without adult supervision.

DO NOT laminate sharp or metal objects (eg: staples, paper clips).

DO NOT laminate heat-sensitive documents (eg: tickets, ultrasounds etc) on

hot settings.

DO NOT laminate with self-adhesive pouches on hot settings.

DO NOT laminate an empty pouch.

IMPORTANT SAFETY INSTRUCTIONS - KEEP FOR FUTURE USE

• Always put item into the appropriate sized pouch.

• Always test laminate with a similar size and thickness before final

process.

• If required, trim excess material from around the item after lamina-

tion and cooling.

• For best results, use Fellowes ® brand pouches:

Enhance 80, Impress 100, Capture 125, Protect 175, Preserve 250

(Enhance 80 - cold pouch)

• When working with different pouch thickness’ (temperature settings) it

is recommended to start first with the thinnest pouches.

• Prepare pouch and item for lamination. Place item within pouch

centred and touching the leading sealed edge. Ensure the pouch is not

too large for the item.

FEATURES & TIPS

Performance Technical Data

Format A3 Voltage / Frequency / Current(Amps) 220-240V AC, 50/60Hz, 5A

Entry width 320mm Wattage 1000 Watts

Pouch thickness (min) 75 microns (per side) Dimensions (HxWxD) 58 x 30 x 14 cm

Pouch thickness (max) 250 microns (per side) Net weight 15 kg

Estimated heat-up time 3 minutes Laminating capacity Max document thickness = 2mm (0.08”)

Cool down time 30-60 minutes Min pouch = 75 micron

Lamination speed Variable speed (0-95 cm/min) (total thickness = 2x75 = 150 micron)

Number of rollers 6 Max pouch = 250 micron

Ready indication Light (total thickness = 2x 250 = 500 micron)

Reverse function Yes

Soft touch buttons + beep Yes

LED interface Yes

Photo capable Yes

Carrier-free Yes

External cooling plate Yes

Let our experts help you with a solution.

Customer Service...

www.fellowes.com

Always call Fellowes before contacting your place of purchase, see the rear

cover for contact details.

NEED HELP?

ENGLISH

405600_EUR_Proteus_All_v1.5.indd 3 12/23/2010 1:50:32 PM
