Bedienungsanleitung Comfy Nest CN-06184 Fritteuse

Bedienungsanleitung

OPERATION INSTUCTIONS:

1.After the machine is powered on, all the indicators and digital tubes will be on for 1 second and then off. At the same time, the

buzzer will ring and the power lamp will be on.

2.Press the

key for 0.5 seconds to start the machine. After the machine is started, the switch light is still always on, and

the light is always on,

and the other lights on the two screens are "--".

3.At this point, consumers choose pot 1 or pot 2 according to their needs

，

Choose

，

then light blink

，

The

corresponding menu indicator blinks. The display of pot 1 lights up and displays the default menu of 360

℉

/15min. The

temperature and time are displayed alternately. The left indicators of the display are displayed Corresponding display; "----" is

displayed on the screen corresponding to pot 2

4.Select the menu you want and press, the corresponding menu light flashing, other menu lights steady on, the display screen

shows the corresponding menu temperature, 3 seconds after no operation, temperature and time display alternately; To

adjust the temperature and time, select the temperature and time selection button first , When the corresponding

indicator on the left side of the display lights up,press to adjust the temperature and time

，

After adjustment, press the

start pause button

，

light is open

，

After startup, the selected menu light is flickers, the machine enters the working

mode, and the display screen displays temperature and time alternately

，

After the machine is working, Menu buttons can no

longer be selected.

5.When selecting pot 2, repeat steps 3 and 4

；

6.When pot 1 menu is selected, no work is turned on

，

choose pot 2

，

light is open

，

Pot 1 displays the menu temperature

and time alternately. Do the same with step 3 and Step 4 for pot 2

，

Press the start pause button when the selection is complete

，

With both pans in working mode, Display screen alternately displays the temperature and time of their menus; If you

choose pot 2, you want to adjust pot 1

，

Press pot 1 first

，

After adjustment, press the start button

，

Both POTS are

in working mode at the same time

；

7.Press the while the machine is working

，

Lights, corresponding menu lights and pot lights flashing, the machine

suspended heating, fan delay 20 seconds stop, two POTS are working, then suspended at the same time; If I want to pause

pot

，

need to select pot

，

Press the on button again

，

Pot 1 is suspended for adjustment. When suspended,

the corresponding display screen displays the program temperature and time alternately; So does pot 2 pause;

FOOD

Min-Max Amount (G)

Time

(min)

Temperature (℉)

Shake

Frozen Fries

200-800

23

400

shake

Chicken Wings

200-800

23

360

shake

Fish

200-800

18

400

shake

Shrimp

200-800

14

400

shake

Steak

100-400

15

360

shake

Pizza

100-400

17

400

Drumstick

200-800

25

400

shake

Chicken

1000-2000

45

400

shake

Vegetables

100-400

8

320

shake

Dessert

200-800

15

340

Grilled Intestines

1000-2000

23

360

shake

Biscuits

100-400

15

340

shake

Note: Add 3 minutes to the preparation time when you start frying while the Hot-air fryer is still cold, When both pans

work at the same time, please extend the working time by 5 minutes.

Cleaning

Clean the appliance after every use.

The pot and the non-stick coating basket. Do not use metal kitchen utensils or abrasive cleaning materials to clean

them, as this may damage the non-stick coating.

1 Remove the mains plug from the wall socket and let the appliance cool down.

Note: Remove the pot to let the Hot-air fryer cool down more quickly.

2 Wipe the outside of the appliance with a moist cloth.

3 Clean the pot and basket with hot water, some washing-up liquid and a non-abrasive sponge.

You can use degreasing liquid to remove any remaining dirt.

Tip: If dirt is stuck to the basket or the bottom of the pot, fill the pot with hot water with some washing-up liquid. Put the

basket in the pot and let the pot and the basket soak for approximately 10 minutes.

4 Clean the inside of the appliance with hot water and non-abrasive sponge.

5 Clean the heating element with a cleaning brush to remove any food residues.

Storage

1 Unplug the appliance and let it cool down.

2 Make sure all parts are clean and dry.

Environment

Do not throw away the appliance with the normal household waste when it is exhausted, but hand it in at an official

collection point for recycling. By doing this, you help to preserve the environment

Guarantee and service

If you need service or information or if you have a problem, please contact your local authorized service centre.

TROUBLESHOOTING

PROBLEM

POSSIBLE CAUSE

SOLUTION

The Hot-Air Fryer does

not work

The appliance is not

plugged in.

Put the mains plug in an earthed wall socket.

You have not set the timer.

Set the timer key to the required preparation time

to switch on the appliance.

8.Long press the power button while the machine is working 2 seconds, the machine rang, the double pot stops working at

the same time, the display screen shows OFF, switch On all other lights off; If you want to turn off pot 1 or pot 2 separately,

select the corresponding or

，

Then long press the power button 2seconds

，

When the corresponding pot stops

working, the corresponding screen displays OFF.

9.Operating status of the machine. If you need to adjust the temperature, select it first or

，

Then select the

temperature and time selection keys respectively Adjust the temperature and time, 5 seconds after adjustment, exit the

debugging mode without operation;

10.Buzzer sound prompt, conventional button operation, short press short ring, long press long ring; The buzzer has 5 prompt

tones, corresponding screen display OFF, corresponding indicator OFF, the same as not working mode;

11.After selecting pot 1 or pot 2, long press the corresponding button to cancel.

12.Memory function: This machine has memory function. For example, when using machine (2), the Drumstick wing menu is used,

the temperature is set to 400

℉

, and the time is set to 20min. After using the machine, the power is not cut off. The memory

function disappeared after 1 hour of power failure.

13.Two POTS working at the same time

，

The key indicator and the corresponding menu indicator of the pot flash once /6

seconds at the same time, and the off time is less than 0.5 seconds

，

after 3 The key indicator light and the corresponding

menu indicator light of the

②

pot flash once /6 seconds at the same time, the extinguished time < 0.5 seconds, the left and right

flashing alternately, the left and right interval time is 3 seconds.

14.Synchronous ending function

：

After turn on, select pot and pot on menu, the 2 pots cooking time differs, press

MATCH

button, and

SYNC

display keeps on, press start button, the time-long pot starts to run, time-short pot shows “HOLD”,

cease running, when both pots reach same time long, then they run synchronously.

15

、

Copy menu function: After turn on, set temp/time of one pot, press

MATCH

button,

MATCH

display keeps on, the other unset

pot copy the same menu function with the set one, and press power button , both pots run under the same menu; when they

start to run, copy display off, this button fails to act.

Settings

This table below will help you to select the basic settings for the ingredients.

Note: Keep in mind that these settings are indications. As ingredients differ in origin, size, shape as well as brand, we

cannot guarantee the best setting for your ingredients.

Because the Rapid Air technology instantly reheats the air inside the appliance instantly

Pull the pot briefly out of the appliance during hot air frying barely disturbs the process.

Tips

-Smaller ingredients usually require a slightly shorter preparation time than larger ingredients.

-A larger amount of ingredients only requires a slightly longer preparation time, a smaller amount of ingredients only

requires a slightly shorter preparation time.

-Shaking smaller ingredients halfway through the preparation time optimizes the end result and can help prevent

unevenly fried ingredients.

-Add some oil to fresh potatoes for a crispy result. Fry your ingredients in the Hot-air fryer within a few minutes after you

added the oil.

-Do not prepare extremely greasy ingredients such as sausages in the Hot-air fryer .

-Snacks that can be prepared in a oven can also be prepared in the Hot-air fryer

-The optimal amount for preparing crispy fries is 500 grams.

-Use pre-made dough to prepare filled snacks quickly and easily. Pre-made dough also requires a shorter preparation

time than home-made dough.

-Place a baking tin or oven dish in the Hot-air fryer basket if you want to bake a cake or quiche or if you want to fry fragile

ingredients or filled ingredients

-You can also use the Hot-air fryer to reheat ingredients. To reheat ingredients, set the temperature to 300℉ for up to 10

minutes.

PROBLEM

POSSIBLE CAUSE

SOLUTION

The ingredients fried

with the air fryer are not

done.

The amount of ingredients

in the basket is too big.

Put smaller batches of ingredients in the basket.

Smaller batches are fried more evenly.

The set temperature is too

low.

Set the temperature key to the required

temperature setting ( see section “setting” in

chapter “Using the appliance”

The preparation time is too

short.

Set the timer to the required preparation time

(see section “Settings” in chapter “Using the

appliance”.

The ingredients are fried

unevenly in the air fryer.

Certain types of

ingredients need to be

shaken halfway through

the preparation time.

Ingredients that lie on top of or across each other

(e.g. fries) need to be shaken halfway through the

preparation time. See section ‘Settings’ in

chapter ‘Using the appliance’.

Fried snacks are not

crispy when they come

out of the air fryer.

You used a type of snacks

meant to be prepared in a

traditional deep fryer.

Use oven snacks or lightly brush some oil onto

the snacks for a crispier result.

I cannot slide the pan

into the appliance

properly.

There are too much

ingredients in the basket.

Do not fill the basket beyond the MAX indication.

The basket is not placed in

the pot correctly.

Push the basket down into the pot until you hear

a click.

White smoke comes

out of the appliance.

You are preparing greasy

ingredients.

When you fry greasy ingredients in the air fryer, a

large amount of oil will leak into the pot. The oil

produces white smoke and the pot may heat up

more than usual. This does not affect the

appliance or the end result.

The pot still contains

grease residues from

previous use.

White smoke is caused by grease heating up in

the pan . make sure you clean the pan properly

after each use.

Fresh fries are fried

unevenly in the air fryer.

You did not use the right

potato type.

Use fresh potatoes and make sure they stay firm

during frying.

You did not rinse the

potato sticks properly

before you fried them.

Rinse the potato sticks properly to remove starch

from the outside of the sticks.

Fresh fries are not

crispy when they come

out of the air fryer.

The crispiness of the fries

depends on the amount of

oil and water in the fries.

Make sure you dry the potato sticks properly

before you add the oil.

Cut the potato sticks smaller for a crispier result.

Add slightly more oil for a crispier result.

CORRECT DISPOSAL OF THIS PRODUCT

This marking indicates that this product should not be disposed with other

household wastes throughout the EU. To prevent possible harm to the

environment or human health from uncontrolled waste disposal, recycle it

responsibly to promote the sustainable reuse of material resources. To return

your used device, please use the return and collection systems or contact the

retailer where the product was purchased. They can take this product for

environmental safe recycling.
