PRECAUTIONS AND GENERAL ADVICE
To get full satisfaction from your hob, please read these instructions carefully and keep them for future
consultation
• These instructions are only valid for those Countries where the destination abbreviations are mentioned on the product
description sheet and on the hob.
• Keep the packaging material (plastic bags, polystyrene parts, etc.) out of the reach of children, as they are potentially
dangerous.
• Check whether the hob has been damaged during transport and remove any protective film from the appliance parts.
• This hob (Class 3) is designed solely for household use for cooking food. Any other use (such as heating
rooms) is to be considered improper and, as a consequence, dangerous.
• Ensure that the installation and gas/electrical connections are performed by a qualified technician in
compliance with current local safety regulations.
• This appliance should only be installed and used in well-ventilated rooms, in accordance with current
regulations. Carefully read the instructions before installing and using this appliance.
• Gas adjustment and supply pressure are indicated on the rating plate located under the hob. If the
appliance is arranged for a type of gas different from that available, refer to the paragraph “Ajustment to
different types of gas”.
REFERENCE TO LOCAL REGULATIONS
Regulation for room ventilation
Note: If the appliance is not equipped with safety devices on the burners (thermocouples), the air vents must be increased by
100%, and must be at least 200 cm
2
), in compliance with M.D. 21 April 1993.
Connection to gas supply
Before connecting the appliance, make sure that the gas supply system complies with standards UNI-CIG 7129 and
UNI CIG 7131.
Gas connection
The connection to the mains gas network or gas cylinder must be made using a rigid copper or steel pipe with fittings
complying with standards UNI-CIG 7129, or using a continuous-surface stainless steel hose complying with standards
UNI-CIG 9891.
The maximum length of the hose is 2 m.
The pressure control valves to be used must comply with the UNI EN 12864 standard for gas cylinders and the UNI EN 88
standard for piped methane gas.
PROTECTING THE ENVIRONMENT
1. Packaging
The packaging material is entirely recyclable, and is marked with the recycling symbol , which identifies it as a type of
material that must be sent to local waste-disposal centres.
2. Product
This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or on the documents accompanying the product, indicates that this appliance may not be
treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical
and electronic equipment.
Disposal must be carried out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you purchased the product.
IT
Declaration of conformity
• This hob has been designed, constructed and marketed in compliance with:
- safety requirements of EEC “Gas” Directive 90/396;
- safety objectives of the “Low Voltage” Directive 2006/95/CE (which replaces 73/23/CEE and subsequent
amendments);
- protection requirements of EEC “EMC” Directive 2004/108/EC;
-requirements of EEC Directive 93/68.
• This hob is suitable for contact with foodstuffs and complies with EEC (CE) Regulation n. 1935/2004.
NOTES:
• Improper use of the grids can result in damage to the hob surface. Do not position the grids upside down or drag them
across the hob.
• If the hob has a glass ceramic top, do not use:
- Cast iron griddles or terracotta pots and pans
- Heat diffusers (e.g. metallic mesh)
- Two cookers for the same pot
• In case of prolonged use, additional ventilation may be needed (opening a window or increasing the extraction force of
the hood).
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities or lack of experiences and knowledge unless they have been given initial supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Keep children away from the hob when it is in use and do not let them play with the controls or any other appliance
parts.
Warning: the protective rubber feet on the grids represent a chocking hazard for young children. After removing the
grids, please ensure that all the feet are correctly fitted.
• Attention: the glass lid (if provided) may shatter if overheated. Before closing it, make sure that all the burners are off.
After use, make sure that the knobs are in position OFF and close the main gas delivery or cylinder tap
INSTALLATION
TECHNICAL INFORMATION FOR THE INSTALLER
• This product can be embedded in a worktop 20 to 40 mm thick.
• If there is no oven beneath the hob, insert a separator panel that has a surface at least equal to the opening
in the work surface. This panel must be positioned at a maximum distance of 150 mm below the upper
surface of the work surface but, in no case less than 20 mm from the bottom of the hob. In the case that you
intend to install an oven beneath the hob, make sure that it is manufactured by Whirlpool and equipped
with a cooling system. The manufacturer declines all liability if another brand oven is installed beneath the
hob.
• Before installation, make sure that:
- the local gas delivery conditions (nature and pressure) are compatible with the settings of the hob (see the
rating plate and injector table).
- The outer surfaces of the furniture or appliances adjacent to the hob are heat resistant according to local regulations.
- Combustion products are discharged outdoors through specific hoods or wall and/or window mounted electrical fans.
- Continuous natural air circulation is ensured through a clear opening in a wall of at least 100 cm
2
. This wall opening must
be:
a) permanent and in a wall to the outside of the room to be vented;
b) made in such a way that it cannot be obstructed from the inside or outside (not even accidentally);
c) protected by plastic grids, metallic mesh, etc., taking care not to reduce the air vent effective area mentioned above;
d) located near floor level and positioned so as not to interfere with the operation of the exhaust system.
