Bedienungsanleitung ADE KE 1421 Felia Küchenwaage

Bedienungsanleitung

Thank you for deciding to purchase this high-quality product from the ADE Company.

You have purchased a set of scales of the highest technical standard and proven quality.

Please read through this operating manual carefully before starting-up the scales for the

first time, and keep it in a safe place so that this information is available to you when you

need it.

1. Start-up

Inserting the batteries:

Open the battery compartment cover on the underside of the scales and insert the

provided batteries (2 x 1.5V AA). Please be mindful of the correct polarity of the batteries

(+/-).

Safety information:

Please take care not to let any objects fall onto the scales,

otherwise the scales could be damaged.

Only clean the scales with a damp cloth. Do not use any solvents or

abrasive cleaning products. Do not immerse in water. All plastic

parts of the scales should be cleaned immediately after contact

with fat, spices, vinegar and other strongly seasoned and coloured

foodstuffs. Avoid contact with citric acid.

2. Operation

Activating the scales:

Place the scales on an even and firm surface. The scales are operated using highly

sensitive sensor buttons. To activate the scales, briefly touch the -button to the right of

the display. “HI” will first appear on the display. After the scales have stabilised, “0 g” or

“0: 00 lb: oz” will appear depending on the settings. The scales are now ready for

weighing.

Please note: If, after activating the scales, a weight-value is displayed, touch the TARE

button to set the scales to zero.

Units of weight:

To change the unit of weight (g <->lb: oz) activate the scales by touching the -button.

As soon as “HI” appears on the display, touch the -button again. The unit of weight

has now been changed. Please make sure that the scales are set to the unit of weight

relevant to you.

Zeroing-(Tare)-func tion:

By touching the TARE button you can set the scales to “0 g”. Place, for example, a bowl

on the weighing platform, press the TARE button and thus set the scales to “0 g” again.

This process can be repeated as often as you like until the total capacity of the scales

(5 kg) is reached. After removing the weighed item the total weight will be displayed as a

negative value.

Automatic / manua l deactivation of the scales:

If the displayed weight does not change within approx. 20 seconds, the scales

automatically deactivate. In order to conserve battery power, you can deactivate the

scales manually by holding down the -button for approx. 2 seconds.

3. Error messages

“Lo” = Display battery empty – please replace

the batteries with the battery type

intended for your scales (2 x 1.5V AA).

“O-Ld” = Overload indicator –

max. capacity of scales 5kg has been exceeded.

Remove the load from the scales immediately, otherwise the load cell

could be damaged.

4. Technical Data

Weight-bearing capacity x division: Max. 5 kg x 1 g

Dimensions: 131 mm x 179 mm x 23 mm

Batteries: 2 x 1.5V AA (contained in product package)

We reserve the right to make technical modifications in the course of further development.

6. Warranty

ADE guarantees the free correction of defects resulting from material or manufacturing

faults through repair or exchange for 3 years from the purchase date. Please get your

warranty section filled out and stamped by the retailer when you make your purchase. In

case of warranty, return the scales to your retailer along with the warranty section

indicating the reason for your complaint.

CE compliance

This device suppresses electromagnetic interference in

accordance withthe applicable EC directive 2004/108/EG

Please note: Under extreme electromagnetic influences e.g. when operating a radio

device in immediate proximity to the scales, the indicator value may be affected. After the

disturbing influence has stopped, the product may once again be used as intended,

although a re-activation may be necessary.
