Bedienungsanleitung ADE KE 1130 Helia Küchenwaage

Bedienungsanleitung

Thank you for purchasing this high-quality product made by ADE. You have acquired a

set of scales that meet the highest technical standards and are of proven quality.

Please read these operating instructions carefully before using the product for the first

time and keep them in a safe place where you can find them whenever you need the

information contained in the instructions.

1. Putting into Service

Safety guidelines:

Ensure that no objects fall onto the scales; otherwise, the scales

may be damaged.

Only use a damp cloth to clean the scales. Never use solvents

or abrasive cleaners. Do not put the scales under water. You

must clean all the plastic parts of the scales immediately after

they come into contact with grease, spices, vinegar or any other

strongly spiced or coloured foods. Avoid any contact with citric

acid.

2. Operation

Before using the scales for the first time, or if the balance was stored in the dark, the

memory capacity has to be recharged before use with a light intensity of at least

100 LUX ± 5 LUX as follows:

1

st

. time: charging time 130 sec. / service life 60 sec.

2

nd

. time: charging time 40 sec. / service life 80 sec.

Full charge time: service life 100 sec.

Switching on the scales:

Place the scales on a firm, level base with a light irradiation of at least 100 LUX and wait

until the solar symbol ☼ flashes.

The scales are equipped with highly sensitive touch buttons. To switch-on the scales

touch the ON/OFF-button right below the display. The display initially shows at first all

characters. After the scales have stabilised, they display "0 g" or 0.00 oz“, depending on

the setting. The scales are now ready to weigh.

Units of weight:

Touching the UNIT-button allows you to change country-specific units of weight

(g = grammes / oz = ounces). Please ensure that the scales are set to the appropriate

units of weight for you.

Tare func tion:

Touching the TARE-button allows you to set the scales to "0 g". Place a bowl, for

example, on the platform of the scales, touch the TARE-button and in this way set the

scales back to "0 g" (is the weight to be tared heavier than 100 g appears next to the

bottom of the display the tare-icon "T. You can repeat this procedure as often as you

like until the total capacity of the scales (5 kg) has been reached. After you remove the

item(s) to be weighed, the total weight is displayed as a minus value.

Automatic- / manua l switch-off the scale

If the indicated weight does not change within approx. 20 seconds, the scales will

automatically switch-off. You can switch-off the scales manually by touching the ON/OFF-

button for approximately two seconds after you have finished using them.

3. Indications

☼ = Sufficient energy available – The scale is ready for use.

“EEEE“ = Overload display – The 5 kg maximum capacity of the scales has been

exceeded. Immediately remove the load from the scales; otherwise, the

load cell could be damaged.

4. Technical Data

Capacity x graduation: max. 5 kg x 2 g

Dimensions: 230 mm x 250 mm x 20 mm

Subject to technical changes due to further-development of the product.

5. Guarantee

ADE guarantees to rectify any defects due to material or manufacturing defects by means

of repair or replacement free of charge for a period of three years. When purchasing,

please have the guarantee card signed and stamped by the retailer. When making a

guarantee claim, please return the scales together with the guarantee card to your retailer

and stating the reasons for the claim.
