Bedienungsanleitung ADE BA 1409 Carlotta Waage

Bedienungsanleitung

Thank you for purchasing this high-quality product made by ADE. You have acquired a

set of scales that meet the highest technical standards and are of proven quality.

Please read these operating instructions carefully before using the product for the first

time and keep them in a safe place where you can find them whenever you need the

information contained in the instructions.

1. How does the body analyser work?

Through this new revolutionary scales you will be able to get information about your body

composition with reference to your weight, body fat %, body water %, muscle mass %

and bone mass kg. First of all you have to enter once your personal data like body

height, age, gender and sports activity under your selected personal memory location.

Afterwards a measurement is as simple as on a normal bathroom scale. You have only to

select your personal memory location, step on the scales and within a few seconds your

measured values will be indicated. The analysis is based on the measurement of the

body’s electrical resistance. A low, safe electrical signal passes freely through fluids

contained in lean tissue, such as muscle and blood, but meets resistance passing

through fat tissue. The body analyser accurately measures the resistance and with

reference to your personal data use it to calculate elements of body composition.

2. How to use

If possible the measurement should be done undressed but always barefoot.

By nature a body is subject of fluctuations (for example: loss of water after taking

exercise or after a sauna visit, after a meal, etc.). To enable comparable readings it is

important to take the measurements as possible always under the same conditions.

In order to ensure that the results of analysis are accurate and consistent, please keep

the measurement conditions constant always at the same daytime. In the morning,

directly after you’ve woken up, your body will be dehydrated and also the majority of fluid

will be stored in the central trunk area. This means that the resistance is relatively high

because of the poor conductivity in the body. By intensify moving during the day

progresses the fluid becomes more evenly distributed through the limbs and increasing

the accuracy of the readings. To get a realistic result it is important to take your readings

at the same time and under the same conditions every day. The easiest way to stick the

rule, measure always in the morning, 15 minutes after you’ve got up, either before or

after you’ve gone to the bathroom.

In spite of a very low electrical signal, this body analyser is not suitable for persons

with heart pacemaker or other electronic medical implants! There is no risk for

persons with none electronic implant for instance a titanium plate in the knee. However,

metal conducts the electric current extremely well and therefore the scale implicates the

body fat value “beautified” – means the actual body fat value is higher as indicated.

However, tendencies may be determined as well.

8. Error Messages

“Err“ = Overload display – The 180 kg maximum capacity of the scales has

been exceeded. Immediately remove the load from the scales;

otherwise, the load cell could be damaged.

Or: Inaccurate weighing- / measuring process - If the scales, for

example, does not stand stable or you do not stand stationary on the

weighing platform.

“Lo“ = Indication that the battery is flat – Please replace the batteries with

the intended 1.5 V type AAA.

“ErL“ = Fat portion % too low – under 5% can not be indicated.

“ErH“ = Fat portion % too high – over 50% can not be indicated.

8. Technical Data

Capacity x graduation: max. 180 kg x 100 g

Display resolution: body fat: 0.1% / body water: 0.1%

Display resolution: muscle mass: 0.1% / osseous mass: 100g

Personal storage spaces: 10

Age: 8 – 100 years

Body height: 80 – 240 cm

Dimensions: 330 mm x 320 mm x 25 mm

Batteries: 2 x 1.5V AAA display / 4 x 1.5V AAA scales (included)

Subject to technical changes due to further-development of the product.

9. Guarantee

ADE guarantees to rectify any defects due to material or manufacturing defects by means

of repair or replacement free of charge for a period of three years. When making a

guarantee claim, please return the scales together with the sales slip to your retailer and

stating the reasons for the claim.

CE conformity

This device is interference-suppressed in accordance with

the applicable EU directive 2004/108/EC

Note: Extreme electromagnetic influences, e.g. when operating radio communication

equipment is being operated next to the scales, can affect the displayed value. When the

interference is over, you can use the product for its intended purpose again; it may be

necessary to switch it on again.

Statutory notice of liability for disposal of batteries:

Batteries are not domestic refuse. As a consumer, you are legally liable to return used

batteries. You can return your used batteries to the public collection points in your area or

anywhere where batteries of the respective type are sold.
