Bedienungsanleitung TOMY TD350 Digital Plus Babyphone

Bedienungsanleitung

Timer

Battery Icon

Indications on the

Baby Unit

If the Vibrate Alert on the Parent Unit is switched ON (See ‘Vibrate Alert’ section within this booklet), the audible

alarm will be accompanied with a vibrating motion.

•••

••

Low Battery –

Parent Unit

Low Battery –

Baby Unit

• The battery icon will ash.

•

Button will change from

green to ashing red.

Alarm tone on

Parent Unit

Alarm Meaning

Indications on the Parent Unit

• The border of the battery icon will ash.

• Button will change from green to

ashing red.

• Flashing battery icon.

•

Button will change

from green to ashing red.

Loss of contact.

Search Animation

Sequence Icon

• Flashing search animation sequence. • Flashing search

animation sequence.

(Continuous)

3 beeps

2 beeps

••••••••

• GETTING TO KNOW YOUR MONITOR

PARENT UNIT

Volume Control Wheel

On/Off Button

Nightlight On/Off Button

Timer Button

Microphone

Vibrate Alert Button

Sound Activation Button

Docking Station

Mains Cable Tidy

Timer Icon

Nightlight Icon

Vibrate Alert Icon

Sound Activation Icon

Sound Level Lights Display

Timer

Battery Icon

Temperature

Gauge

Movement

Sensor Pad

Display*

Temperature Sensor

Timer Button

ON/OFF (& Pager) Button

Nightlight On/Off Button

Microphone

Timer Icon

Temperature Gauge

BABY UNIT

LCD Display

• PARENT UNIT

Remove the battery compartment cover from the back of unit (N.B: this may already be supplied loose) and insert

the battery pack (supplied) correctly, connecting the plug with the socket. Replace the cover and screw rmly into

position, referring to the Quick Start Guide for pictorial reference.

Ensuring the power cable is correctly connected, place your Parent Unit into the Docking Station and charge for a full 6 hours.

You can use your monitor while it is charging by following the ‘Set Up’ guide below.

Important! Your Parent Unit will not function without rst inserting the battery.

• BABY UNIT

For best performance we recommend that the Baby Unit is powered by your domestic mains supply using the power

adaptor supplied. Alternatively, you can use 4 x AA/LR6 batteries (not supplied) to make it fully portable. To insert the

batteries, unscrew the battery compartment cover on the underside of the unit using a at-head screwdriver. Insert the

batteries, making sure you match the ‘+’ and ‘-’ polarity symbols. Replace the cover and screw rmly into position.

Position the Baby Unit at least 1 metre away from your baby ensuring all parts are kept out of reach. Under no

circumstance should you place any parts of the monitor in or on a cot. For best performance we recommend that the

monitor is placed no further away than 3 metres from your baby.

GB GB

Belt Clip

Attachment

2-Way Talkback

Button

LCD Display

• POWER ON

Make sure both the Baby and Parent Units are plugged into the mains and/or have their batteries installed (see

above). The units should stand at least 1 metre apart.

Press and hold the

button on each unit for at least 2 seconds. Once activated, the buttons will glow.

• BABY AND PARENT UNIT CONNECTION

As each unit activates, watch for the animation sequence on the LCD

screens as the Baby and Parent Units auto-search and link to each other.

Once a connection is made between Baby and Parent Units, normal monitoring

will start. The above mentioned connection s

equence

is replaced on the LCD

screens on both units with the ambient temperature from the Baby Unit.

• ALARM MODES

Identify the cause of audible alarm by using the following table; should you be unable to identify or rectify the

cause of the problem, please refer to the Simple Solution Guide within this booklet.

• SET UP

Activation Sequence

* See ‘Accessories’ section.

2 3
